Electric Greenhouse Curtain Gear Winder

US$ 61 - 71 MOQ: 20 Sets

Key Specifications

Size:

Small

Type:

Other, gear motor, Customised Motor

Cover Material:

Other, steel

Beijing Aling Agri-Facilities Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Size Small

Type Other, gear motor, Customised Motor

Cover Material Other, steel

Model Number 120

Place of Origin Beijing, China

Brand Name SLC

Material Other, steel

SLC-DJ40 Electric Roll-up Motor Performance Parameter
Model SLC-DJ40
Power Rating	40W	Output Shaft Rotate Speed	≈3.8rpm
Voltage Rating	DC24V	Max Revolving Rounds	≥55 turns
Rated Current	3.0A	Travel Adjustment Accuracy	≤2mm
Maximum Output Current	4.0A	Rolling Length	≤60m
Maximum Output Torque	40N.m	Body Weight	2.4Kg
Maximum Lifting Weight	≤100 KG	Outside Measurement (L. x W. x H.)	239mm×102mm×131mm

SLC-DJ80 Electric Roll-up Motor Performance Parameter
Model SLC-DJ80
Power Rating	80W	Output Shaft Rotate Speed	≈3.8rpm
Voltage Rating	DC24V	Max Revolving Rounds	≥55 turns
Rated Current	4.0A	Travel Adjustment Accuracy	≤2mm
Maximum Output Current	6.0A	Rolling Length	≤100m
Maximum Output Torque	80N.m	Body Weight	2.8Kg
Maximum Lifting Weight	≤150 KG	Outside Measurement (L. x W. x H.)	239mm×102mm×131mm

SLC-DJ150 Electric Roll-up Motor Performance Parameter
Model SLC-DJ150
Power Rating	150W	Output Shaft Rotate Speed	≈3.3rpm
Voltage Rating	DC24V	Max Revolving Rounds	≥55
Rated Current	9.0A	Travel Adjustment Accuracy	≤2mm
Maximum Output Current	10.0A	Rolling Length	≤150m
Maximum Output Torque	150N.m	Body Weight	3.6Kg
Maximum Lifting Weight	≤180 KG	Outside Measurement (L. x W. x H.)
