Help Center2 Core Indoor Terminal Box White
Related Products
Description:
With protective doors, dustproof
Suitable for many types of modules, used in cabling work area subsystem
Embedded type surface, easy for installation and removal
Available for fiber optic SC simplex or LC duplex and can be used in both surface mounted
installation and concealed panel installation
All modules are solder less mode
2. Application:
Optical fiber communication system
Fiber optic CATV, FTTH Fiber to the Home
Optical fiber access network
Testing instruments, fiber optical sensors
Fiber optic patch panels, cabinet type or wall-mounted type fiber optic distribution units
3. Technical Data:
Item Parameters
Scope of application 3.0 x 2.0 mm drop cable or indoor cable
Fiber Cladding Diameter 125μm ( 652 & 657 )
TBF Diameter 250μm & 900μm
Applicable Mode Singlemode & Multimode
Tensile strength >50 N
Operating temperature -40~+85℃
Adapter SC & LC
Insertion loss ≤0.2dB(1310nm & 1550nm)
Insertion loss 2
Send Inquiry to This Supplier
