---2015automatically OTR tire cutting machine
is to separate 2 rings(sidewalls) from OTR tire.
Structure:
this machine is made up of rotary plate,rotary gearing,locking device,fix tire bead device,beam,wheel,blade working device.
Main parameter:
(1)model: QKF2400
(2)process range:1600-2400mm(max diamter<4000mm can be processed)
(3)equipped with power:three phrase four line 380V 50Hz
(4)motor power: 7.91KW
(5)capacity:3-10pieces/h
(6)weight:about 1500kg
(7)size: 2900×2400×2630mm(l*w*h)
main advantage:
1.single electric cabinet to control whole operating process
2.automatically cooling water device
3.automatically cutting process,no harm to labors
4.foundation can be made to cover machine for removing tire easily
---2014 OTR tire cutting blocks machine is to cut OTR tire into some pieces.
Structure:
this machine is made up of rotary beam,blade working device,cooling water device.
Main parameter:
(1)model: QG1000
(2)process range:1600-2400mm(max diamter<4000mm can be processed)
(3)equipped with power:three phrase four line 380V 50Hz
(4)motor power: 5.87KW
(5)capacity:3-10pieces/h
(6)weight:about 1200kg
(7)size: 2500×1000×1800mm(l*w*h)
main advantage:
1.single electric cabinet to control whole operating process
2.automatically cooling water device
3.automatically cutting process,no harm to labors
4.foundation can be made to cover machine for removing tire easily
---Welcome inquiry from overseas friends,Contact us at any time!
Tel:+86(0)373 3033288
Fax: +86(0)373 3692059
mobile:+86 15936531984
skype:wjangelabaibai
Address:Xinpu Road,Xinxiang City,Henan Pro.China
