High Shear Emulsifier(Vacuum Type)
High-Shear Emulsifier (Vacuum type) is non-standard designed and manufactured according to customer's production
processing. It is suitable for materials requiring for being emulsified and mixed under vacuum condition. Low-speed scraper is recommended to work together when emulsifying and mixing materials with high viscosity. It can work
together with inline high shear emulsifier to carry out dispersing, emulsifying, homogenizing and mixing processes.
Following systems are optional according to requirement: Batching System, Discharging System, Cooling/Heating Temperature
Control System, Vacuum System, Nitrogen Protection System, Condensation and Recovery System, PH Value On-line
Measurement and Control System, CIP Cleaning System etc.
It is with wide application range and the processes are controllable.
It can be up to Sanitary Grade at request for mid batch or industrial production in industries such as medicine, food, cosmetic etc.
[Production Capacity]: 2-2000L
[Applicable Materials]:Applicable for production process for solution, gel, suspension or emulsion of solid - liquid, liquid- liquid materials such as juice, soup bases, milk production, tissue homogenate, cosmetics, surfactants, asphalt, emulsifier, oil field chemicals etc.
Model |
Design volume (L) |
Capacity (L) |
Blending power (kw) |
Blending speed (rpm) |
Emulsifying power (kw) |
Emulsifying speed (rpm) |
Electrical heating power (kw) |
Vacuum pump power (kw) |
Lifting |
SZJ-5 |
6 |
5 |
0.37 |
0-100 |
0.75 |
0-2880 |
2 |
0.37 |
Manual |
SZJ-10 |
10 |
8 |
0.37 |
0-100 |
0.75 |
0-2880 |
2 |
0.37 |
Manual |
SZJ-30 |
30 |
25 |
0.75 |
0-86 |
1.5 |
0-2800 |
2 |
0.37 |
Electric |
SZJ-50 |
50 |
40 |
1.5 |
0-86 |
2.2 |
0-2880 |
2 |
0.37 |
Electric |
SZJ-100 |
100 |
80 |
1.5 |
0-86 |
4 |
0-2880 |
6 |
0.37 |
Electric |
SZJ-150 |
150 |
120 |
2.2 |
0-86 |
5.5 |
0-2800 |
6 |
0.75 |
Electric |
SZJ-200 |
200 |
160 |
2.2 |
0-86 |
5.5 |
0-2880 |
8 |
0.75 |
Electric |
SZJ-250 |
250 |
200 |
4 |
0-86 |
7.5 |
0-2880 |
12 |
0.75 |
Hydraulic |
SZJ-350 |
350 |
280 |
4 |
0-86 |
7.5 |
0-2800 |
12 |
1.5 |
Hydraulic |
SZJ-500 |
500 |
400 |
5.5 |
0-65 |
11 |
0-2880 |
15 |
1.5 |
Hydraulic |
SZJ-650 |
650 |
520 |
5.5 |
0-65 |
15 |
0-2880 |
18 |
3 |
Hydraulic |
SZJ-850 |
850 |
680 |
7.5 |
0-65 |
18.5 |
0-1440 |
18 |
3 |
Hydraulic |
SZJ-1000 |
1000 |
800 |
7.5 |
0-65 |
18.5 |
0-1440 |
24 |
3 |
Hydraulic |
SZJ-1300 |
1300 |
1000 |
11 |
0-45 |
22 |
0-1440 |
24 |
4 |
Hydraulic |
SZJ-2000 |
2000 |
1600 |
15 |
0-45 |
30 |
0-1440 |
36 |
5.5 |
Hydraulic |
Remarks:
* The capacity is data based on water as medium. The model selection shall be based on the data such as the materials
viscosity, density etc..
* Special operation condition, such as high temperature, high pressure, explosive, combustible and corrosive etc, details are
required for correct model selection.
* If any change in the above table, subject shall prevail without notice.
* The table cannot include all products, please contact with our sales engineers for more information.
