Specifications
VL-520 Packing machine with auger filler:1.Stainless steel servo driven auger filler
2.Touch-Screen
3. High Filling Accuracy
VL-520 Packing machine with auger filler:
Main Features
- Servo driven film transport system.
- Servo-driven, intermittent motion end seal jaws.
- User-friendly PLC and touch screen operation interface allowing for multilingual operation and access restriction features.
- Comprehensive synchronisation for date printer and feeding systems.
- Simple and fast bag size changeover with one-piece forming sets.
- Jam detection/ alert to prevent product jam between the sealing jaws
- Photocell for centring printing.
- Completely outfitted with Stainless Steel in order to provide durability as well as sanitation.
- Every unit comes equipped with hot foil printer
The various packaging applications include
- Free Flow Powders: Sugar, Salt, Pepper, Spices, Flour, Semolina, Milk powder, various sorts of powders, etc. [non-food: detergents, plaster, talc, chemical additives]
- Granules & Seeds: Coffee beans, Cocoa, Rice, Sesame, Seeds, Small Granules etc.
- Dry, Frozen & Processed Foods: Snack foods [popcorn/chips], Cereal & Health Foods,
- Confectionary, Biscuits & Bakery, Pasta, Grated Cheese, Nuts, Dried fruits and vegetables, Frozen Vegetables, Dried Mushrooms, Pet Food.
- Fresh Foods: Fresh Produce
- Non Food: Medium- Nuts, Small metal/plastic items, Bolts, Washers, Auto, Electrical and Plumbing Parts etc.
3.2 Technical Parameters
Basic technical specifications VANWELL VL-520
Bag size: L=100-390mm, W=75-245mm
Packing range: 15-1000g (depending on the materials)
Fill roll: Laminated Film [OPP/CPP, OPP/PE, MST/PE, PET/PE, N/PE, OPP/EVA, EVA/PE]
Thickness: 0.04-0.08mm
Max. output/ speed: 40-100 bag/min depending on bag length, output of used dosing device, product character, dosing size and required dosing accuracy.
Electricity Consumption: 220 V, 50 Hz, 3.5KW
Air Consumption: 6kg/cm, 0.25m3/min
Weight: 600kg
Machine dimensions: 1400mm x 1500mm x 2100mm (L x W x H)
Available dosing systems
- Auger doser,
- (Volumetric) Cup filler,
- Multihead weigher,
- Linear weighers,
- Liquid doser.
Usable types of packaging materials
The VL-520 machine is equipped with thermal jaws enabling the use of all standard thermal weldable materials, such as:
- Laminated Al foil with polyethylene
- Paper laminated with polyethylene
- Polypropylene film
- As well as a number of special films [e.g. monolayer film]
Dosing Systems
Stainless steel servo driven auger filler
This computer controlled, brushless, direct drive, servo driven system provides superior fill accuracy.
Touch-Screen
The touch screen comes equipped with an intuitive, icon-based, user-friendly interface which enables an easy, fast as well as accurate system control.
Filling Accuracy
The digital servo motor provides a shaft resolution of 1/5000 per revolution. This precise control means the auger is consistent providing fill accuracies of ± 1%.
Construction
Standard electronics, enclosure with stainless steel, contact parts & aluminium structural parts.
Technical information
Capacity: 1 1000 grams (20-60 time/M)
Auger diameter: 20- 59 mm
Total power: 2.3 Kw.
Servo motor power : 2.0 Kw
Hopper size: 50 Ltr.
