Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050

Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050 thumbnail-1
Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050 thumbnail-2
Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050 thumbnail-3
Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050 thumbnail-4
Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050 thumbnail-5
Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050 photo-1
Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050 photo-2
Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050 photo-3
Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050 photo-4
Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050 photo-5
US$ 1 - 15 MOQ: 5 Meters
Key Specifications
Get Latest Price
LED Light Source:
LED
Type:
Flex LED Strips
Input Voltage(V):
DC12V /24V
Contact Supplier Request Quote Chat Now
Shenzhen Helian Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source LED
Type Flex LED Strips
Input Voltage(V) DC12V /24V
Lamp Power 24
Lamp Luminous Flux(lm) 2400
Color Temperature(CCT) RGB+white+wram white
Working Temperature(℃) 20, 50
Working Lifetime(Hour) 50000
Lamp Body Material PVC
Certification CE
Emitting Color Other, RGB+white+wram white
Place of Origin Guangdong, China
Brand Name Helian
Model Number Flex LED Strips

Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050





Product Specification:


--2.4Watt per meter,30LEDS per meter



--3.84Watt per meter,48LEDS per meter



--4.8Wattt per meter,60LEDs per meter;



--7.68Watt per meter,96LEDS per meter



--9.6Watt per meter,120LEDS per meter



--Dimension: 5000*11*4.5mm


--Working voltage: DC12V, DC24V;



--Viewing angle 120Deg.


--Light source: High brightness SMD LED 3528;


--Emitting Colors:Red,Green,Blue,Yellow,Warm White,Pure White,Cool White, RGB Color. and other color;


--PCB Color: White,Black,Yellow (copper)


--Certificate: CE,Rohs


--Net weight:0.25kg/roll



--QTY/Carton 65roll /carton


--Carton size: 54X27X34cm


--Gross Weight: 17kg/Ctn







Product Parameters:



 Model

 Length

LED Source

 LED Quantity

 Beam Angle

 Voltage

 Emitting Color

 (M)

 (SMD)

 (LED/Roll)

 (Degrees)

 (V DC)

 HL-RX3528-F3

 5

 3528

30/48/60/96/120

120

12V/24V



 HL-GX3528-F3

 5

 3528

30/48/60/96/120

120

12V/24V



 HL-BX3528-F3

 5

 3528

30/48/60/96/120

120

12V/24V



 HL-RX3528-F3

 5

 3528

30/48/60/96/120

120

12V/24V



 HL-WWX3528-F3

 5

 3528

30/48/60/96/120

120

12V/24V

3000-3500K

 HL-WX3528-F3

 5

 3528

30/48/60/96/120

120

12V/24V

4000-4500K

HL-CWX3528-F3

 5

 3528

30/48/60/96/120

120

12V/24V

6000-6500k





 Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050



Features:




1. Long life span of over 50,000 hours;




2. Flexible & slim form, cut table at every 3LEDs;




3. with 3M self-adhesive tape for easy installation onto most flat surfaces;




4. Emit higher brightness with super bright SMD Led’s;




5. Produce even color between strips at the tightest color tolerances;




6. Low heat generation, no heat damage.





Photo Show:



 Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050

Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050



Applications:


1. Decorative lighting (cove lighting, back lighting) for homes, hotels, stores, yachts, bars, automobiles etc;


2. Illumination lighting in any places that you want to take the place of conventional illumination for your purpose of reducing heat output;


3. Guidance Lighting for cinemas, theaters, yachts, trains to guide people move around safely;



4. Channel letter lighting for your stores, restaurants, bars etc., Shop display lighting for your articles.

Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050



Package:

Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050





How to connect Flexible strip to power supplies:

Best Led Lighting Factory 12V/24V Led Strip Light SMD3528 5050

Certificate:



Our Factory And Equipment:

Our Services:



1. Once receive your inquiry, we will response within 24 hours.



2. Professional R&D team, strong technical support.



3. Provide a whole set of sample pack (Sample Fee: Negotiate).



4. Factory manufacturing, offer you the best price with high quality products.





Payment And Shipment:



1, Payment terms: Western Union, T/T,Paypal.

    Please remember to leave the correct contact information for delivery.



2, Shipping terms: DHL, UPS, FEDEX, TNT, EMS





Welcome to ask details:



Address:           3F,West 4#, Songbai Road, Shiyan Town, Bao'an District, Shenzhen, Guangdong 518108

Hot-line:             0755-27606785

SKYPE:             Keloe Jiang
