ACS Dual Boost II NFC/ IC Chip RFID Card Reader and Writer ACR1281U-C1
The DualBoost Series has PC/SC compliance for both contact and contactless interfaces. It makes the use of high-speed communication for contactless cards at a maximum of 848 kbps, which makes it suitable for highly demanding applications. It also provides intelligent support for hybrid and combo cards, such that it detects a contactless card even that has been incorrectly placed in the contact card slot. Lastly, the DualBoost has a built-in SAM slot for added security in both contact and contactless applications.
With additional features such as USB firmware upgradability, contact memory card support and extended APDU support, ACR1281U-C1 DualBoost II is a highly cost-effective, powerful all-in-one device that offers convenience and flexibility to many smart card applications.
Features
Compliance with CCID.
Supports major contactless smart cards that conform to ISO14443 Type A and B.
Built-in antenna for contactless tag access, with card reading distance of up to 50 mm (depending on tag type).
Supports new Mifare Plus and DESFire EV1.
T=CL emulation for Mifare 1K/4K Cards.
Read/write speed of up to 848 kbps for contactless interface.
Built-in anti-collision feature (at least 1 card is detected when multiple cards are presented).
Supports extended APDU.
Supports major contact smart cards that conform to ISO7816.
Supports memory cards such as SLE5528, SLE5542, etc.
Read/write speed of up to 344 kbps for contact interface.
Durable landing type smart card connector.
Built-in SAM card slot.
Intelligent support for hybrid and combi cards.
Firmware Upgradable.
User-controllable monotone buzzer and LEDs.
USB Full Speed (12 Mbps).
Typical Applications
e-Government
e-Banking and e-Payment
e-Healthcare
Transportation
Network Security
Access Control
Loyalty Program
More Details
Dimensions |
120.5 mm (L) x 72 mm (W) x 20.4 mm (H) |
Weight |
150g |
Interface |
USB 2.0 Full Speed |
Operating Distance |
Up to 50 mm (depends on the tag type) |
Supply Voltage |
Regulated 5 V DC |
Supply Current |
200mA (max); 100mA (normal) |
Operating Temperature |
0-50°C |
Humidity |
10 - 80 % |
Operating Frequency |
13.56MHz |
Smart Card Interface Support |
|
Compliance/Certifications |
Germany nPA certified, PC/SC, CCID, CE, FCC, RoHS Compliant, Microsoft WHQL: 2000, XP, Vista, 7 |
Operating System Support |
|
