Fluke 62 MAX Handheld Dual Laser IR Infrared Thermometer Gun -30 to 650
US$ 120 - 190
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Fluke
Model Number:
62 MAX
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UNI-T UT71B Intelligent Digital MultimetersUS$ 119 - 140MOQ: 1 Set -
UNI-T UT302C Infrared ThermometersUS$ 99 - 140MOQ: 1 Set
-
ETCR6000 AC/DC Clamp Leaker Meter AC: 45Hz-400Hz AC600VUS$ 105 - 145MOQ: 1 Set
-
Kyoritsu 2007A Digital Clamp MetersUS$ 106 - 130MOQ: 1 Set
-
PROVA CM-01 DC/AC Digital Clamp Meter TES High Resolution DC/AC 10mAUS$ 174 - 200MOQ: 1 Set
Place of Origin
China
Brand Name
Fluke
Model Number
62 MAX
Product Description
Description
Why IR Thermometers? Temperature is often the first indication of potential problems in electrical and mechanical applications. But how can you easily determine if an electrical panel has a hot spot, a motor is overheating or an HVAC system is inefficient? The answer is with an infrared (IR) thermometer. With handheld, non-contact IR thermometers, you can instantly measure equipment temperatures in hard-to-reach or hazardous areas. And with early detection of abnormal temperatures comes early correction of problems.
Fluke 62 MAX and Fluke 62 MAX+
Designed with your on-the-job needs in mind, the new Fluke 62 MAX and 62 MAX+ infrared thermometers are everything you’d expect from the experts in measurement tools. Small in size, extremely accurate and very easy to use. IP54 rated for dust and water resistance. Precise yet rugged enough to take a 3-meter drop. In fact, the 62 MAX and 62 MAX+ are so tough, they’re the only IR thermometers around you can handle without care.
Key Benefits
|
Additional Features
- Distance to spot: Precise laser technology makes for more accurate and repeatable measurements.
- Dual lasers: The 62 MAX+ has dual rotating lasers to help you identify area to be measured. The measurement area is the spot between the dots.
- Large, backlit display: Large screen makes data easier to read, even in dark areas.
- Min/Max/Avg/Dif: Displays the minimum, maximum or average temperature, or the difference between two measurements.
- Alarm: Hi and Lo alarms for rapid display of measurements outside the limits.
- Power: Both the 62 MAX and 62 MAX+ are powered by a single, standard AA battery.
Specifications
Temperature Range
| Fluke 62 MAX | -30 °C to 500 °C (-22 °F to 932 °F) |
| Fluke 62+ MAX | -30 °C to 650 °C (-22 °F to 1202 °F) |
Accuracy
| Fluke 62 MAX | ±1.5 °C or ±1.5% of reading, whichever is greater -10 °C to 0 °C: ±2.0 -30 °C to -10 °C: ±3.0 |
| Fluke 62+ MAX | ±1.0 °C or ±1.0% of reading, whichever is greater -10 °C to 0 °C: ±2.0 -30 °C to -10 °C: ±3.0 |
Response Time (95%)
| Fluke 62 MAX | <500 ms (95% of reading) |
| Fluke 62+ MAX | <300 ms (95% of reading) |
| Spectral Response | 8 to 14 microns |
| Emissivity | 0.10 to 1.00 |
Optical Resolution
| Fluke 62 MAX | 10:1 (calculated at 90% energy) |
| Fluke 62+ MAX | 12:1 (calculated at 90% energy) |
Display Resolution
| 0.1 °C (0.2 °F) |
Repeatability of Readings
| Fluke 62 MAX | ±0.8% of reading or <±1.0 °C (2 °F), whichever is greater |
| Fluke 62+ MAX | ±0.5% of reading or <±0.5 °C (1 °F), whichever is greater |
Power
| AA battery |
Battery Life
| Fluke 62 MAX | 10 hours with laser and backlight on |
| Fluke 62+ MAX | 8 hours with laser and backlight on |
Physical Specifications
| Weight | 255 g (8.99 oz) |
| Size | (175 x 85 x 75) mm (6.88 x 3.34 x 2.95) inches |
| Operating Temperature | 0 °C to 50 °C (32 °F to 122 °F) |
| Storage Temperature | -20 °C to 60 °C (-4 °F to 140 °F), (without battery) |
| Operating Humidity | 10 % to 90 % RH non-condensing at 30 °C (86 °F) |
| Operating Altitude | 2000 meters above mean sea level |
| Storage Altitude | 12,000 meters above mean sea level |
| IP Rating | IP 54 per IEC 60529 |
| Drop Test | 3 meters |
| Vibration and Shock | IEC 68-2-6 2.5 g, 10 to 200 Hz, IEC 68-2-27, 50 g, 11 ms |
| EMC | EN 61326-1:2006 EN 61326-2:2006 |
Standards and Agency Approval
| Compliance | EN/IEC 61010-1: 2001 |
| Laser Safety | FDA and EN 60825-1 Class II |
