High Quality Silicone Fiberglass Braided Sleeve For Cable Management
PRODUCT INTRODUCTION
High Quality Silicone Fiberglass Braided Sleeve For Cable Management is non-alkali fiberglass braided then coated with silicone resin and treated in high temperature.
SPECIFICATION
Item |
Performance |
Note |
|
Dielectric Breakdown Voltage KV AC |
Minimum Average |
≥2.5 |
Before Aging |
Minimum Single Point |
≥2.0 |
||
Minimum Average |
≥1.5 |
6 Hrs* 245±5ºC 245±5ºC 6Hrs Aging |
|
Minimum Single Point |
≥1.0 |
||
Thermal Endurance |
No Indication of Crack |
OK |
6 Hrs* 245±5ºC 245±5ºC 6Hrs Aging |
Fire Resistance |
VW-1 |
OK |
UL 1441 |
DIMENSION
Inside Diameter |
Wall Thickness (mm) |
Standard Package (m/roll) |
|
Nominal (mm) |
Tolerance (mm) |
||
φ0.5 |
+0.2, -0.1 |
≥0.30 |
200 |
φ1.0 |
+0.2, -0.1 |
≥0.30 |
200 |
φ1.5 |
+0.2, -0.1 |
≥0.30 |
200 |
φ2.0 |
+0.2, -0.1 |
≥0.30 |
200 |
φ2.5 |
+0.3, -0.1 |
≥0.35 |
200 |
φ3.0 |
+0.3, -0.1 |
≥0.35 |
200 |
φ4.0 |
+0.3, -0.1 |
≥0.35 |
200 |
φ4.5 |
+0.3, -0.1 |
≥0.40 |
100 |
φ5.0 |
+0.3, -0.1 |
≥0.40 |
100 |
φ6.0 |
+0.3, -0.1 |
≥0.40 |
100 |
φ7.0 |
+0.3, -0.1 |
≥0.45 |
100 |
φ8.0 |
+0.3, -0.1 |
≥0.45 |
100 |
φ9.0 |
+0.3, -0.1 |
≥0.55 |
100 |
φ10.0 |
+0.3, -0.1 |
≥0.55 |
100 |
φ12.0 |
+1.0, -1.0 |
≥0.55 |
50 |
φ14.0 |
+1.0, -1.0 |
≥0.55 |
50 |
φ16.0 |
+1.0, -1.0 |
≥0.55 |
50 |
φ18.0 |
+1.0, -1.0 |
≥0.55 |
50 |
φ20.0 |
+1.0, -1.0 |
≥0.65 |
25 |
φ25.0 |
+1.0, -1.0 |
≥0.65 |
25 |
φ30.0 |
+1.0, -1.0 |
≥0.65 |
25 |
APPLICATION
High Quality Silicone Fiberglass Braided Sleeve For Cable Management with its good dielectric strength, flexibility and flame retarding properties makes it high performance qualities. It can be widely used in insulated or partially insulated conductors, bus bars, component leads, or assemblies of electrical components etc.
