with ISO 9001:2008 standard UL RoHS Reach certifications silicone for dip coat on fibre glass sleeves
1. Model
SB-SGS-25
2. Working Temperature
200°c
3. Structure
UL ROHS REACH certifications silicone for dip coat on fibre glass sleeves are braided with non-alkali fiberglass and then coated by silicone resin processed in high temperature.
4. Characteristics
1) good dielectric strength, flexibility and resistance property
2) breakdown voltage: 2.5kv
3) thermal endurance: no crack (245±5°c 6hrs aging)
4) fire resistance: VW-1 UL1441
5) certifications: CUL, RoHS, REACH, SGS, CQC
5. Dimension
INSIDE DIAMETER |
WALL THICKNESS MINIMUM (mm) |
STANDARD PACKAGE (m/roll) |
|
NOMINAL(mm) |
TOLERANCE(mm) |
||
φ0.5 |
+0.2, -0.1 |
≥0.30 |
200 |
φ1.0 |
+0.2, -0.1 |
≥0.30 |
200 |
φ1.5 |
+0.2, -0.1 |
≥0.30 |
200 |
φ2.0 |
+0.2, -0.1 |
≥0.30 |
200 |
φ2.5 |
+0.3, -0.1 |
≥0.35 |
200 |
φ3.0 |
+0.3, -0.1 |
≥0.35 |
200 |
φ4.0 |
+0.3, -0.1 |
≥0.35 |
200 |
φ4.5 |
+0.3, -0.1 |
≥0.40 |
100 |
φ5.0 |
+0.3, -0.1 |
≥0.40 |
100 |
φ6.0 |
+0.3, -0.1 |
≥0.40 |
100 |
φ7.0 |
+0.3, -0.1 |
≥0.45 |
100 |
φ8.0 |
+0.3, -0.1 |
≥0.45 |
100 |
φ9.0 |
+0.3, -0.1 |
≥0.55 |
100 |
φ10.0 |
+0.3, -0.1 |
≥0.55 |
100 |
φ12.0 |
+1.0, -1.0 |
≥0.55 |
50 |
φ14.0 |
+1.0, -1.0 |
≥0.55 |
50 |
φ16.0 |
+1.0, -1.0 |
≥0.55 |
50 |
φ18.0 |
+1.0, -1.0 |
≥0.55 |
50 |
φ20.0 |
+1.0, -1.0 |
≥0.65 |
25 |
φ25.0 |
+1.0, -1.0 |
≥0.65 |
25 |
φ30.0 |
+1.0, -1.0 |
≥0.65 |
25 |
6. Application
UL ROHS REACH certifications silicone for dip coat on fibre glass sleeves have good dielectric strength, flexibility and resistance property. It is widely used in insulated, uninsulated and partially insulated conductors, busbars, leads and electrical components.
7. More Products to Choose
8. Our Services
1) 2~7 working days
2) 2 years quality guarantee
3) prompt feedback
4) 24hrs on line service
9. Packaging & Shipping
0.5~1.5mm 200m/r
2.0~6.0mm 100m/r
7.0~18.0mm 50m/r
20.0~30.0mm 25m/r
All our products are packaged in cardboard boxes.
You can choose the best way you like to deliver the goods, such as DHL, FEDEX, UPS...
10. Company Information About SUNBOW
Shenzhen SUNBOW Insulation Materials MFG. Co., Ltd is one of the leading insulation sleeving manufacturers in China. It was established in 2003. In 2008, due to the business expansion, it is relocated in Heshuikou SUNBOW industrial park. In 2009, we succeeded in getting ISO9001:2008 quality management system certification. We specialize in fiberglass sleevings, PE heat shrink tubes, PVC heat shrink tubes, PTFE heat shrink tubes and silicone rubber tubes. Our products have passed UL, CSA, RoHS, REACH certifications. Our business partners can be found all over the world. Some famous partners are:
SEB, Philips, Zoppas, Toshiba, Sanyo, SAMSUNG, Midea, HOT, IKEA, Breville, Panasonic, Tescon, Tiger, Emerson, Conair....
11. Some Certifications We've Got
12. Other services
Free samples can be provided for your trial.
13. Frequently Asked Q & A
Q1. You are a factory or trading company?
We are a factory and we can provide best price and high quality products for you.
Q2. Can you accept sample orders?
Yes, we can accept sample orders and we can also provide free samples for your test if necessary.
Q3. What is your MOQ?
Normally, 2000m per size.
Q4. What are your payment terms?
T/T 100% or West Union
Q5. How can I get my order? How can I know you sent the goods?
We will send the goods by UPS, DHL, FedEx or sea shipment. After we sent the goods , we will give you the tracking number or other relative files for your check.
Q6. How about your quality?
Try a small order, and then you can judge.
Q7. Have you passed any certificates?
Yes. We are an ISO9001:2008 quality management system certificated manufacturer. Our products have passed UL, ROHS, REACH certifications. If necessary, we can send you relative files.
Q8. Are there any advantages to choose your products?
1) Factory direct sales, quality assurance and competitive price
2) UL, ROHS, REACH certificated
3) Philips, Toshiba, Midea etc. well-known partners
4) An extensive line of high quality products (silicone fiberglass sleeving, various heat shrink tubes, pvc tube, ptfe tube, FDA compliance silicone rubber tube…)
15. Other Models
SB-SGS-12(for 1.2kv silicone fiberglass sleeving)
SB-SGS-15(for 1.5kv silicone fiberglass sleeving)
SB-SGS-25(for 2.5kv silicone fiberglass sleeving)
SB-SGS-30(for 3.0kv silicone fiberglass sleeving)
SB-SGS-40(for 4.0kv silicone fiberglass sleeving)
SB-SGS-70(for 7.0kv silicone fiberglass sleeving)
SB-SGS-100(for 10.0kv silicone fiberglass sleeving)
