Parameter and Drawing Specifications:
Description Color |
Type |
Terminal Grey |
TR-10N-02 |
|
End Cover Grey
|
|
|
Fixed Bridge
|
FBI 10-10 Imax: 76A |
|
Insertion Bridge
|
|
|
Separating Plate
|
TS-KK3 |
|
Partition Plate
|
|
Zack Strip White |
ZB10 |
Screwdriver |
SZS 1.0×4.0 |
Rail Material |
aluminum |
Dimensions mm |
10.2/56.5/- |
Height (U35: 7.5/U35: 15G 32) mm |
59/66.5/64 |
Screw / Torque Nm |
M4 / 1.5-1.8 |
Stripping Length mm |
11 |
IEC Technical Data |
|
Max. Load Current / Cross Section A / mm2 |
76 / 16 |
Rated Surge Voltage / Contamination Class KV / - |
8 / 3 |
Surge Voltage Category |
Ⅲ |
Competitive Advantage:
1. Stable good quality
2. Competitive price
3. Quickly response
4. Full range products for selection
5. Flexible to design the exact part per customers’ demand
