DGP 16-16-6 Water Production Line
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Beverage, Medical, Chemical
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DG Series Carbonated Drinks Constant Pressure Filler Production LineNegotiableMOQ: 1 Set -
CAPPING MACHINEUS$ 3,500 - 3,500MOQ: 1 Set
-
Water Treatment(Water Treatment Equipment, Water Filter, Pure Water Machine)US$ 4,000 - 75,000MOQ: 1 Set
-
GFP Series Automatic Washing Filling and Capping LineUS$ 7,000 - 12,000MOQ: 1 Set
-
Mineral Water in Plastic Bottle Production LineUS$ 9,500 - 12,000MOQ: 1 Set
Condition
New
Application
Food, Beverage, Medical, Chemical
Packaging Type
Bottles
Packaging Material
Wood
Automatic Grade
Automatic
Driven Type
Pneumatic
Place of Origin
Zhejiang, China
Brand Name
Huili
Model Number
DGP-16-16-6
Specifications
DGP 16-16-6water production line (Filling Production Line,water bottling machine,water filling machine,filling machine)
Product Description
The equipment is used in production of non-soda drink of fruit juice, fruit wine, minerals and pure water packed in polyester bottles. Washing, filling and capping are integrated in one machine.
The most advanced technology from Japan and Germany is employed in the design. The gravity fixed liquid surface filling is used. The filling is fast, the amount of liquid is accurately controlled and the dropping and leakage are avoided.
Spring cramps are used in the bottle washing process. The empty bottles can be turned over180~ along the conveying rail. There are two times of internal and external washing, the efficiency of bottle washing is high.
The magnetic torque is used for screw capping. The power of screw capping can be adjusted without steps. The power of the screw capping can be adjusted without steps. The power of the screw capping can also be fixed, and the caps will not be damaged, the capping is reliable.
The whole machine is controlled by PLC with touch-screen as the human-machine interface. The amount of the drinks in the storage tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle. When bottles are cramped wrongly or when caps are not available, the machine can be stopped automatically.
The frequency changing technology is used to adjust the operation speed steplessly. The production capacity can be displayed digitally and can be adjusted conveniently.
The equipment is used in production of non-soda drink of fruit juice, fruit wine, minerals and pure water packed in polyester bottles. Washing, filling and capping are integrated in one machine.
The most advanced technology from Japan and Germany is employed in the design. The gravity fixed liquid surface filling is used. The filling is fast, the amount of liquid is accurately controlled and the dropping and leakage are avoided.
Spring cramps are used in the bottle washing process. The empty bottles can be turned over180~ along the conveying rail. There are two times of internal and external washing, the efficiency of bottle washing is high.
The magnetic torque is used for screw capping. The power of screw capping can be adjusted without steps. The power of the screw capping can be adjusted without steps. The power of the screw capping can also be fixed, and the caps will not be damaged, the capping is reliable.
The whole machine is controlled by PLC with touch-screen as the human-machine interface. The amount of the drinks in the storage tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle. When bottles are cramped wrongly or when caps are not available, the machine can be stopped automatically.
The frequency changing technology is used to adjust the operation speed steplessly. The production capacity can be displayed digitally and can be adjusted conveniently.
Specification
Model |
DGP 16-16-6 |
DGP 18-18-6 |
DGP 24-24-8 |
DGP 32-32-10 |
DGP50-50-8 |
Capacity (600ml)(b/h) |
3000-4000 |
5000-6000 |
6000-10000 |
10000-12000 |
15000-18000 |
Filling precision |
±5MM |
||||
The size of bottle(mm) |
Diameter ofφ50-φ100 height 150-320 |
||||
Suitable cap shape |
Plastic screw cap |
||||
Water pressure of washing bottle (Mpa) |
0.18 |
||||
Water of washing bottle(Kg/h) |
800 |
1600 |
2500 |
3500 |
4000 |
Gas Source pressure |
0.4(Mpa) |
||||
Gas Consumption(m3/min) |
0.3 |
0.3 |
0.4 |
0.5 |
0.5 |
Total power(KW) |
2.20 |
3.75 |
5.6 |
6.2 |
10.00 |
Total weight (Kg) |
2500 |
3500 |
4200 |
8000 |
10000 |
Dimension (mm) |
2300×1750×2250 |
2480×1960×2250 |
3200×2180×2400 |
4000×2200×2500 |
4500×2500×2500 |
