| Series : | Labeling Machine |
| Name : | TB-1100 Two sides labeling machine |
| Model : | TB-1100 |
Main Parameters:
This series labeling machine implementation in cylindrical, flat products on the circumference of a label or sticker, such as glass bottles, plastic bottles, etc.,
It can realize the circumference of a circle, a half circle positioning labeling,
and other functions, are mainly vertical labeling and horizontal labeling in two ways.
Profile class labeling machine implementation on the side of the plane,
side of the workpiece surface label or sticker, such as flat bottle, cosmetics boxes, etc.
The machine control by PLC, it keep many files,it it onle need adjust again for different size,
it also can label two sides.label speed and rolls of speed accurate is simultaneous. Label smoothly,
roll label around circumference, can label the whole or part of the objects, can also add the printer .
This machine also can be used to square bottle. This machine can use for cone object after installing the special device additional.
it can with date coder machine.
Specification:
Model |
TB-1100 |
Applicable object |
flat, ellipse and erose object |
Speed (bottle/min) |
0-120 |
Precision (mm) |
±1 |
Size objects (mm) |
width:30-300,thickness:20-130 |
Size of label H (mm) |
15-170 |
Size of label L (mm) |
15-300 |
Power (kw/V) |
500W |
Dimension (mm) |
2440×1200×1600 |
Weight (kg) |
480 |
