High Speed Computer Gravure Printing Machine

High Speed Computer Gravure Printing Machine thumbnail-1
High Speed Computer Gravure Printing Machine photo-1
US$ 18,000 - 25,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Textiles
Packaging Type:
Other, woodencase
Contact Supplier Request Quote Chat Now
Wenzhou Huili Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
WENZHOU
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Textiles
Packaging Type Other, woodencase
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Place of Origin Zhejiang, China
Brand Name HUILI
Model Number High speed computer gravure printing machine

Specifications

This machine is suitable for multi-colour coce-through continuous printing for such roll film materials with excellent printing

Performance and Characteristics

Use:This machine is suitable for multi-colour coce-through continuous printing for such roll film materials with excellent printing performance as BOPP,PET,PVC,PE,aluminium foil and paper,etc.

Performance and Characteristics
1.Every control module of the automatic colour register system is equipped with microprocessor and can correct the deviation of colour register quickly and accurately.
2.The main machine adopts frequency control of motor speed.
3.Eeleasing tension adopts full-automatic tension controller and magnetic powder brake.
4.Rolling adopts full-automtic constant tension and tracion coordinated with torque DC motor, double-station automatic turnover, replacing the matrrial without stopping the machine.
5.Two-layer airproof structure for drying oven provides uniform wind flow, while specific cooling fin of stainless steel for heating tube provides energy-saving opportunity, uniform temperature as well as anti fire possibility.
6.Pneumatic system is adopted for press roller and traction roller.
7.Automatic ink circulation system is provided.
8.Air shaft is used for unwinding and rewinding shaft providing convenient assemble and unassemble possibilities.
9.It is provided with display of press line speed and accumulated length in meter.
10.Quality cast-iron structure for the whole set provides good stability and vibration absorbing capability.

Main Teachnical Variables

ModelSWASY-800

Effective Printing Width800mm

Max.Width of base Material850mm

Max.Printing Speed150m/min

Max.Mechanical Speed600mm

Inside Diameter of Roll Core of Base Materrial76mm

Diameter of Printing Plate Roller120~300mm

Modified Accuracy of Computer Registration±0.2mm(wholeMachine)

Control Range of Tension0~25kg/FullWidth

Heating Power of Oven50kw

Total Power of Machine65kw

Weight of Machine10000kg

Overall DImensionsL12400×W2500×H2350mm

SWASY-800
