Help CenterHL-130 Type of Horizontal Auto-packing Machine
Related Products
-
Stabilized Voltage SupplyNegotiableMOQ: 1 Set -
7 Sticks Hotdog Maker MachineNegotiableMOQ: 1 Set
-
High Efficiency Fresh-keeping Film Sealing MachineUS$ 60 - 80MOQ: 2 Units
-
Soft Film Package Tissue Paper Packing Machine / Napkin Paper Packing Machine / Tissue Paper Packing MachineNegotiableMOQ: 1 Set
-
Hot Sale V Shape Powder MixerUS$ 3,000 - 4,000MOQ: 1 Set
Specifications
1.Initiative film shaft2.An independent bag former
3.A 3-side and 4-side sealing device
4.An automatic materiall control
HL-130 type of horizontal auto-packing machine is suitable for packing foodstuff. Pharmacy eutical pesticide,and daily using chemical etc. Different filling methods can be used for different products such as liquid. Powder.Granule and so on.
Feature:
Choices for mutilple sealing types of international standard.Safety protection by mutilple layers to keep products from penetration.
Visible during the packing ,easy to learn the operation, convenient and quick to adjust package size.
Technical Parameter:
- Pouch Width 60mm-140mm
- Pouch Length 70mm-180mm
- Max Volume 90ml
- Speed 30-70 pouch/min.
- Pacing Accuracy <±1.5%
- Reel 400mm
- Electricity Consumption 3.5KW
- Air Consumption 0.6m3/min
- Weight 750KG
- Size (L×W×H) 2500mm×940mm×1370mm
The main characteristics of equipment
1. Bag system:Bagging, sealing and filling is relatively independent of the system,The packaging can be adapted to different objects, package size and shape.
2. Product packaging system:Using heat sealing packaging materials (polyethylene, multilayer composite coating), the automatic bagging completed. measures such as packaging filling and sealing process fully automated production facilities. Trilateral closure pocket or bag is a four-sided flat closure. Use different forms of filling machine, and packaging different products.
3. Control System:PLC programmable computer controller inverter and so on, high integration, the ability to control and reliable operation .Touch screen technology enabled applications to operate machines more reliable and convenient .Photoelectric sensor, encoder, the switches are close to the EMport of advanced sensors. machinery and electronics
integration has been a perfect performance.
