High Quality Cheap Price Solid Tungsten Carbide Rods From Manufacturer

Name: High Quality Cheap Price Solid Tungsten Carbide Rods From Manufacturer
Brand: ATM Carbide
SKU: 100678611

US$ 50.00 - 50.00 MOQ: 1 Kilogram

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

ATM Carbide

Model Number:

Standard

Shanghai ATM Cemented Carbide Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name ATM Carbide

Model Number Standard

Material Carbide

Diameter 1-50mm

Type End Mill

Coating Other, titanium

Overall Length 50-330

Product Description

Solid tungsten carbide rods from manufacturer.

Advantages :

1. Professional cemented carbide manufacturer with high tech equipment and experienced engineers.

2.Garantee customers's satisfaction

2. Certificate of ISO 9001

3. 100% pure raw material

4. OEM or ODM

Detailed Images

Grade of the rods

Grade	ISO Grade	Grain Size(μm)	Cobalt Content(%)	Hardness(HRA)	Density(g/cm3)	T.R.S(N/m㎡)	Application
GU10UF	K05-K10	0.4	6.0	94.0	14.80	3800	Ultrafine grain size,with amaizing ware resistance.High ware resistance endmill and engraving tools are recommended.Suitable for cutting PCB and composite material.
GU15UF	K10-K20	0.4	8.5	93.5	14.52	3800	Ultrafine grain size,with ware resistance.High ware resistance endmill and engraving tools are recommended.Suitable for cutting PCB and plastic.
GU25UF	K20-K40	0.4	12.0	92.5	14.10	4200	Ultrafine grain size,higher Co content,with excellent hardness and toughness.Endmill and reamer are recommended.Excellent performance for finishing.Especially suitable for cutting steel(HRC:45-55),AI alloy and Ti alloy
GU20F	K20-K40	0.6	10.3	92.3	14.30	3800	Drill and endmill are recommended.Especially suitable for cutting stainless steel,heat resistant alloy,cast iron
GU20	K20-K40	0.8	10.3	91.7	14.40	3500	Drill and endmill are recommended.Suitable for cutting general steel (HRC<48),grey cast iron,stainless steel,heat resistant alloy.
GK05A	K15	1.0	6.0	92.5	14.95	2450	Drill,endmill and bur are recommended.Especially for cutting non-ferrous metal and graphite(coating is needed)
