Cctv Tester Vandal-proof Housing Design Waterproof Security HD 1080P SDI CCTV Camera

Name: Cctv Tester Vandal-proof Housing Design Waterproof Security HD 1080P SDI CCTV Camera
Brand: ENSTER
SKU: 100789239

US$ 1 - 88 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ENSTER

Model Number:

EST-SDI3552

Shenzhen Enster Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ENSTER

Model Number EST-SDI3552

Type Digital Camera

Style Dome Camera

Sensor CMOS

Technology Infrared

Special Features Vandal-proof

feature:

Housing VandalProof Design
IP66 Weatherproof
Lens:Varifocal 2.8-12mm
Adjustable Zoom&Focus
Built-in 30 pieces IR-LED
IR Range:25m

specification:

model number	EST-SDI3552
Camera Type	Color Weatherproof IR Camera
Total Pixels	2010(H) x 1108(V) = 2,227,080
Effective Pixels	1944(H) x 1092(V)= 2,122,848
Min. Illumination	Color : 1.0 lux, BW : 0.5 lux,
Min. Illumination	Color DSS : 0.002 lux, BW DSS : 0.0008 lux
Video Output	Digital : BT.1120, HD-SDI, Analog : NTSC/PAL CVBS(w/o WDR)
S/N Ratio	More than 50dB (AGC off)
Function
Lens	DC/Manual
AGC	0 – 20 steps
Shutter Speed	AUTO/MANUAL(1/50(60) ~ 1/60,000 sec)
Digital Slow Shutter	Off/On(x4)
Brightness	0 - 20
WDR	Off/On(Level Adjustable)
Day&Night	Auto/Color/B&W
White Balance	Auto/Auto ext/Pushing/Manual
3D.DNR	Off/Low/Middle/High
AGC	Off/On
Mirror	Off/On
Flip	Off/On
Sharpness	0 – 10 steps
Shading	Off/On
Digital Zoom	0 – 96 steps
Privacy Mask	32 Masks
Language	Korean/Chinese/English
Camera
Lens Mount	Varifocal Lens 2.8 -12mm
Infrared Luminary	30 pieces IR-LED
Infrared Wavelength	850 nm
Illuminate Distance	More than 25m
Video Connector	HD-SDI: BNC connector(SMPTE 292M compatible), CVBS: BNC connector
Supplied Voltage	DC12V Voltage
Power Consumption	IR On: 400mA max., IR Off: Less than 130mA
