H.264 video compression 1080P portable 4G wifi transmitter made in China
COFDM wireless transmission system advantages:
1. Long range transmission distance
2. Real-time transmission systems
3. Delay time very short less than 500ms
4. Perfect image quality, brighter colors and image smoothness.
(we will support video to demonstration it if you sent inquiry)
4G portable device Technical Parameters:
1. H.264 video encoding compression, dual stream out put
2. Real-time local video recording, multi video mode
3. Quik start, can work normaly within 25s once power on
4. Support remote PTZ control
5. Multiple 4G network options, compatible with 3G, support wifi
| Item | Description |
| Picture Process | Mega Pixels CMOS |
| Resolution | 1080P/30F |
| Minimal Illumination | Infrared on 0 Lux |
| Lens | f=3.6mm, 10 times zoom, anti infrared microscope |
| IR_CUT | Infrared and color filter can be automatically switched |
| Horizontal Angle | 355° |
| Vertical Angle | ≥90° |
| Presets | 6 |
| Infrared Light Control | Automatically controlled by photosensitive resistance, also can be manually controlled |
| Irradiation Distance | Over 10m |
| Main Stream | 1080P (1920*1080)/ 1280*720/ 640*480 |
| Second Stream | 640*360/ 320*180 |
| Video Compression | H.264/JPEG |
| Maximal FPS | 30 FPS |
| Data Rate | 1.024Mbps~4.096Mbps |
| Sub Data Rate | 128kbps~1024kbps |
| Picture Orientation | Mirror/Inversion |
| Character Overlay | Support |
| Audio Compression | G.711/G.726 |
| Basic Protocol | TCP/IP, HTTP, SMTP, RTSP, FTP, DHCP, DDNS, UPNP, NTP |
| Other Protocol | 802.11b/g/n, 4G |
| Mobile APP | Support |
| Video Control | Support |
| Dual Voice Transmission | Support |
| Storage | SD card (can store capturing picture and video) |
| SD card Preview | Can remotely control SD card, and download |
| Motion Detection | Support 4 zones |
| Alerting Notification | Email/FTP/SD card/External Alerting/Sending notifications to alerting server |
| User Setup | Third Grade User Permission |
| Date/Time Setup | Support |
| Upgrate | Can update by network |
| Ethernet Interface | 10Base-T/100Base-TX |
| Storage Interface | SD card slot |
| Alerting Input | 2 Channels |
| Alerting Output | 1 Channel |
| Audio Input | 1 Audio input hole |
| Audio Output | 1 Audio output hole |
| Control Interface | RS485 |
| Antenna Interface | 4G/WIFI |
| Power Supply | DC 12V |
| Power Consumption | <8W |
| Working Temperature | -20℃~60℃ |
| Humidity | 10%~80% Freezing free |
Applications include:
1.Government surveillance
2.Law Enforcement
3.Urban combat training with many multiple RF reflections
4.Unmanned vehicles: UAV, UGV, USV
5.Covert Surveillance
6.Robots
7.Portable microwave products
Our Services:
1. we accept all terms of trade
2. we provide professional system design and construction
3. Lifelong maintenance
4. 24-hour technical support
5. we have 9 years experience in wireless transmission area, we are professional factory, so we can provide you:high quality products,better product pre-sales and after-sales service,attractive prices,shorter delivery.
