LinkAV-NJ340-20W TDD Base Station Equipment

Name: LinkAV-NJ340-20W TDD Base Station Equipment
Brand: LinkAV
SKU: 100942529

US$ 1 - 1,500 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

LinkAV

Model Number:

LinkAV-NJ340-20W

Shenzhen Zhongchuang Technology Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name LinkAV

Model Number LinkAV-NJ340-20W

Features:

1. Modularity , Three security , Low-power electronics , Built-in cooling fan ;

2. Support the system build network within same frequency or different frequency , automatic roam ;

3. Power stability, Adjustable dynamic power ;

4. Dual mode positioning autoadaptation ;

5. The wireless channel adopt either AES128 encryption ;

6. IP Non line-of-sight transparent data transmission , Two-way audio and video communication

Technical Parameters:

Parameter / Type		LinkAV -T331s-10W
RF Parameter	Working Frequency	300~800MHz(Custom)



	Modulation Bandwidth	2 / 4 / 8MHz
	Modulation Type	TDD-OFDM
	Communication Mode	TDMA
	Power Output	≤43dBm
	Flatness In Band	≤ ±0.5dB
	Out-of-band Spurious	≤ -36dBm
	Third-order IM	≤ -36dBC
	RX Sensitivity	≤ -100dBm
	MER	≥ 36dB
	Adjacent-channel interference	≥ 40dB
Data	Synchronization Control	GPS/ Beidou synchronous clock
	Transmission Bandwidth	Max 14Mbps
	Network Protocol	ip/TCP,UDP,HTTP,SMTP etc
Generic Specification	Operating Temperature	-30 ~ +70°C
	Power Input	~100 – 260V
	Power Consumption	≤50W
	Size	2U
	Net Weight	≤10Kg
Connector	Power Interface	Three core power plugs
	Data Connector	RJ45
	RF Antenna Terminal	NF
