ML Series Single Phase ac Electric Motor With Aluminium Shell

Name: ML Series Single Phase ac Electric Motor With Aluminium Shell
Brand: DELLENT
SKU: 101012565

US$ 15 - 200 MOQ: 50 Pieces

Key Specifications

Brand Name:

DELLENT

Model Number:

ML series single phase ac motor

Type:

Asynchronous Motor

Fuan Dellent Electric & Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou China

Delivery Detail:

Delivery time depends on order quantity.

Brand Name DELLENT

Model Number ML series single phase ac motor

Type Asynchronous Motor

Frequency 50HZ , 60HZ

Output Power 0.25 KW to 3.7KW

Protect Feature Waterproof

Phase Single-phase

Certification CCC, CE, CCC, CE, Other, CCC, CE, CCC, CE , SGS, ISO

AC Voltage Other, 220V ,110-240V

Place of Origin Fujian, China

Efficiency Other, IE1 , IE2

Specifications

ML Series Single phase Electric motor
1, reliable quality performance
2, factory directly
3, easy maintainance
4, CE CCC

ML Series Single phase ac Electric motor with aluminium shell

Introduction and Application

Conform to the IEC standard. The motor is with removable feet. User can fit according to their needs.
1. Good performance
2. Safety & reliable operation
3. Nice appearance
4. Easy maintainance
5. Low noises
Contruction Materials
Frame – Aluminium
End shields- Aluminium/Cast iron
Fan cowl- steel
Fan-Plastic
Shaft- Medium carbon steel(stainless available on request)
Terminal box – Aluminium
Operating Conditions:
Power Range	0.25 ~ 3.7KW
Frame Size	71 ~ 112M
Enclosure:	IP44,IP54
Insulation	Class B , F
Voltage	220, 110 ~ 240V
Frequency:	50Hz , 60Hz
Working duty	S1
Speed:	2 Pole , 4 Pole

Note:
The voltage and frequency could be made according to your request.
ML single phase ac motors Technical Data

Model	Output		Current	Power	Eff	Speed	Tstart/Tn	Ist/In	Tmax/Tn
Model	KW	HP	(A)	Factor	(%)	(r/min)	Tstart/Tn	Ist/In	Tmax/Tn
ML711-2	0.37	0.5	2.6	0.95	68	2760	2.2	6.5	1.7
ML712-2	0.55	0.75	3.71	0.95	71	2760	2.2	6.5	1.7
ML801-2	0.75	1	4.92	0.95	73	2780	2.2	6.5	1.7
ML802-2	1.1	1.5	7.02	0.95	75	2780	2.2	6.5	1.7
ML90S-2	1.5	2	9.32	0.95	77	2800	2.2	6.5	1.7
ML90L-2	2.2	3	13	0.95	78	2800	2.2	6.5	1.7
ML100L-2	3	4	18.2	0.95	79	2820	2	7	1.7
ML112M-2	3.7	5	22.1	0.95	80	2820	2	7	1.7
ML711-4	0.25	0.33	1.9	0.95	63	1360	2.2	6.5	1.7
ML712-4	0.37	0.5	2.64	0.95	67	1360	2.2	6.5	1.7
ML801-4	0.55	0.75	3.76	0.95	70	1380	2.2	6.5	1.7
ML802-4	0.75	1	4.98	0.95	72	1380	2.2	6.5	1.7
ML90S-4	1.1	1.5	7.11	0.95	74	1400	2.2	6.5	1.7
ML90L-4	1.5	2	9.44	0.95	76	1400	2.2	6.5	1.7
ML100L1-4	2.2	3	13.7	0.95	77	1410	2	7	1.7
ML100L2-4	3	4	18.4	0.95	78	1420	2	7	1.7
ML112M-4	3.7	5	22.4	0.95	79	1420	2	7	1.7
