Incorporated x-ray tube LED display veterinary mobile radiography x ray
Model:YSX50M
Features:
1. Spring & balancing arm structure
2. Flexible and mobile
3. Incorporated x-ray tube & generator
4. Radiography parameter control by mAs
5. Cable and remote wireless radiography control are both available
6. LED display.
Components:
1. Incorporated tube and generator.
2. Collimator.
3. Controller.
4. Flexible arm.
5. Stand.
Specifications:
Model |
YSX50M Vet Movable x-ray machine |
Power supply |
Voltage: AC220V± 10%, 50/60Hz ± 1Hz |
Output power |
3kW |
X-ray tube |
Focus: 2.6mm fixed anode |
kV adjustable range |
45kV~90kV |
mAs adjustable range |
2mAs-125mAs |
Control mode |
Wire control & wireless remote control |
Operation feature |
Stand column ± 90° rotatable. |
stable performance Medical mobile 50mA cheapest veterinary x ray machine prices
Model:YSX0413
Main features mobile x-ray machine
1.Mobile and only Radiography
2.Used in ward and emergency treatment room for radiography.
3.It is dependable brake ,stable performance, easy operation
4.Wireless remote control device is used and the operation greatly reduces radiation damage
Technical Parameters x-ray machine
power supply
power voltage:220v± 10%,
power Frequency:50Hz±0.5Hz
power Capacity:5kva
Internal resistance:1 Ω
Radiographyx-ray machine
tube voltage:40-90kvp in 11 steps , each step 5KV
tube current:30mA ;50mA totally 2 steps
exposure time:0.05-6. sec altogether 20 steps
Mechanical properties:
1 When the X-ray tube windows is down,the activities scope of distance between the focus and ground is 450mm~1770mm
2 Rotating angle around horizontal axis: ±180°
3 Rotating angle around vertical axis: ±90°
medical mobile LED display 50ma animal x-ray equipment
x-ray machine
x-ray machine
x-ray machine
ultr
50mA mobile veterinary x-ray equipment
Incorporated x-ray tube LED display veterinary mobile radiography x ray machine
