Metal Sheet Stripping Machine
Why choose this stripping machine?
1. Certificate: ISO 9001, CE,
2. Lifetime services
3. Roller cover with 0.05mm chrome; 72mm diameter solid steel shaft. Lifetime>10years.
4. Introduced Mitsubishi PLC with touch screen to machine controll system.
5. One worker operation (minimum)
6. Cr12 mould steel cutter with quenched treatment. Cutting blade with heat treatment.
7. Product cut-to-length.
8. Technician overseas installing and training available
1.Technical parameter of Metal Sheet Stripping Machine
Item |
Specification |
|
|
Material |
Type |
Pre-painted steel coil |
Thickness |
0.3-0.7mm |
|
Width of steel sheet |
Maximum 1250mm |
|
Yield strength |
235-345Mpa |
|
Slitting width |
80mm-1250mm |
|
Slitter material |
Cr12 mould steel |
|
Cutter material |
Cr12 mould steel |
|
Numbers of Slitting blade |
6 pairs or customize |
|
Working speed |
15times/min |
|
Type of cutting |
length-set cutting |
|
Size of machine |
3000mmX1700mmX1400mm |
|
Control mode |
Mitsubishi PLC |
|
Electric condition |
380V/3Phase/ 50HZ |
|
Main motor power |
4 KW |
|
Hydraulic station power |
2.2 KW |
|
2. Components of Metal Sheet Stripping Machine
Decoiler |
1set |
Guiding device |
1set |
Leveling system |
1set |
Hydraulic cutting system |
1set |
Controlling system |
1set |
Slitter device |
1set |
Cutter device |
1set |
Outputs table |
2 pieces |
3.Process flow of Metal Sheet Stripping Machine
Decoiling material→covering film →Guiding system →Slit sheet into pieces →Cut to length
Metal Sheet Stripping Machine
Cutters (Slitting width is adjustable)
1) Q: Are you manufacturer or trading company?
A: We are manufacturer and trading company .
2) Q: Do you provide installing and training overseas?
A: Overseas machine install and worker training services are optional.
3) Q: How is your after sales support?
A: We provide technical support on line as well as overseas services by skillful technicians.
4) Q: How does your factory do regarding quality control?
A: There is no tolerance regarding quality control. Quality control complies with ISO9001. Every machine has to past testing running before it's packed for shipment.
5) How can I trust you that machines pasted testing running before shipping?
A: 1) We record the testing video for your reference. Or,
2) We welcome you visit us and test machine by yourself in our factory.
6) Q: Do you sell only standard machines?
A: No. Most machines are made to order.
7) Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. We are ALIBAB’s Gold supplier with BV assessment (Audit report can be provided).
We joined Alibaba trade assurance. With Trade Assurance, you’re covered for On-time shipment and Pre-shipment product quality (Optional).
8) What should I provide if I`d love to customized my machine?
A: To customize machine, we`d love to know:
1. Profile drawing
2. Raw material: the width(1250mm?), thickness(0.3-0.7mm?), and yield strength of steel coil.
3. Voltage: designed per your requirement
4. Configuration requirement: Hydraulic or manual decoiler/ stacker
Have no idea about them?
We will be glad to recommend machines ----Just let us know your country!
9) How is your cooperate process?
A: Below is the cooperation flow chart
Lifetime services;
Technician can be sent to your factory to install the machine and train your workers
Get Free:
"Send" below to get profile drawing & design technical support by our 15 year experience technicians FOR FREE!
