Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Concrete Machinery > QHS-1500 Series Drink Mixer
QHS-1500 Series Drink Mixer
US$ 3,000 - 7,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
beierde
Model Number:
QHS
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CO2 Filter Carbonated Drink Beverage MachineUS$ 755 - 800MOQ: 1 Piece -
FBZ Pop-top Can Aluminium Can Capping MachineUS$ 4,500 - 8,000MOQ: 1 Unit
-
Filling Line for Carbonated Beverage ,Carbonated Drink Filling Washing Capping MachineUS$ 8,000 - 58,000MOQ: 1 Set
-
Vertical Sticker Labeling Machine, Paper Labeling Machine, Glue Labeling Machine, Non-dry Glue Labeling MachineNegotiableMOQ: 1 Set
-
Semi-Automatic Glass Bottle Washer/ RinserNegotiableMOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
beierde
Model Number
QHS
Processing Types
Carbonated Beverage
Certification
CE, ISO9001, PED
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
QHS-1500 series drink mixer
The mixing principle and the result are similar with QHS-2500,the design technology is simpler and operation is easier,it is the ideal equipment for the middle and small factory.
QGF Series Filling machine Specification
| Model(QHS) | 3000B | 5000B | 7000B | 10000B | 15000B |
| Production Capacity (kg/h) | 3000kg/h | 5000kg/h | 7000kg/h | 10000kg/h | 15000kg/h |
| Water-sugar mixing rate | 3--6 times | ||||
| CO2 content | 3.8times | ||||
| Mixing precision | ≤1.5% | ||||
| Pressure of compressed air (Mpa) | 0.6-1 | ||||
| Consumption of compressed air | 5m3/h | ||||
| Pressure of CO2 (Mpa) | 0.8--1 | ||||
| CO2 consumption (m3/h ) | 2 | 2.5 | 3 | 5 | 5 |
| Pressure of purified water(Mpa) | 0.4-0.8Mpa | 0.4-0.8Mpa | 0.4-0.8Mpa | 0.4-0.8Mpa | 0.4-0.8Mpa |
| Mixing temperature (°C) | < 4°C | < 4°C | < 4°C | < 4°C | < 4°C |
| Heat exchange area (m2) | 8 | 8 | 10 | 12 | 12 |
| Power consumption (kw) | 4.45kw | 5.9kw | 7.2kw | 10.2kw | 13.6kw |
| Overall Dimension (mm) | 2900×1500×2610 | 3000×2000×3000 | 3000×2000×3000 | 3500×2300×3200 | 3800×2600×3200 |
