Brand Name: Maxdor
Model Number:GTC
Door Type : telescoping glass door
Door Material: Glass , aluminum frame
Application type:stores,banks,hotel, Hospitals, restaurants,conference center,exhibition building
Delivery Detail: 10-15 days after receiving customers payment
Packaging Detail: Carton packing
Automatic Telescopic sliding door includes Single open or double open.
Characteristic
*Self programming electronics to automatically set door operation on installation.
*Safety Functions,If the door leaves are hindered when opening, they are immediately stopped.
*The position of the obstacle is stored and will be slowly approached during the next door movement.
Dimensions | |
Clear passage width |
LW 1800-4000mm |
Maximum opening width |
8000mm |
Door leaf weight, max |
4×50kg |
Clear passage height |
LH 2100×3000mm |
Fixed side screens |
Optional |
Telescopic Door Technical data
Opening and closing force, adjustable , max |
150N |
Multiple data adjustable | |
Power supply data |
230V,50/60Hz |
Power consumption |
360W |
Power consumption, average |
30W |
External power supply |
24V, 2A |
Standard Components |
|
1. Motor Drive Unit 2. Transformer 3. Control module 4. Electronic lock 5. Belt connection 6. Belt carrying wheel 7. Locating wheel 8. Mute rubber
|
Optional Accessory |
|
10. Battery pack 11. Cover 220mm 12. Electric mechanical lock or Manual unlocking device 13. Safe barrier or BEA Eagle six safe sensor(with radar curtain) |
*Can choose ES200 control system or GT150 (GT300 ) control system
*All product through CE ,ROHS ,FCC certification, strict quality supervision.
Delivery on time,Quality assurance!
Customer satisfaction, is the biggest pursuit of our services.
Guangzhou Automatic door manufacturer,choose US !!!
Company since its inception has been dedicated to improve research and development of automatic door; always adhere to the quality assurance for business purposes, to "quality and service" for the spirit of the founding of the company.
