Specifications
Industrial Slurry Pump1. Flow Rate: Up to 950 l/s
2. Head: 62m
3. DN: 350mm
4. Max Power: 1200kW
Small Slurry Pump
Slurry Pump is a single stage, single-suction centrifugal pump that is designed to transfort the strong abrasive, corrosive, high concentration slurries in Power, Mining, Metallurgical, Coal, Petrochemical, Building Material, and other industrial applications.
Features:
- AH slurry pumps can be used by series connection for special application request
- The discharge outlet can be adjusted at 8 directions with intervals of 45 degree
- Slurry pump's bearing assembly use cylindrical structure, adjusting the space between impeller and front liner easily. They can be removed completely when being repaired. Bearing assembly use grease lubrication
- High chromium alloy wet parts can stand stong abrosive
- Shaft seal is packing seal with expeller seal, that has excellent sealing performance
- A variety of drive modes( CL,CV,CR,ZL,ZV,ZR) can meet hard operation circumstances
Structure:
1. Volut liner |
2. Pump casing |
3. Back liner |
4. Cover plate |
5. Front liner |
6. Impeller |
7. Suffing box |
8. Shaft sleeve |
9. Shaft Sleeve |
10. Bearing Housing |
11. Pedestal |
12. Grease Cup |
13. Split Packing Gland |
14. Expeller |
15. Expeller Ring |
16. Packing |
17. Water Seal Ring |
18. Lip Seal Ring |
|
|
No. |
Parts |
Material |
1 |
Impeller |
High-chrome alloy: A05, A07, A49 |
Rubber | ||
2 |
Volute Liner |
High-chrome alloy A05, A07, A49 |
3 |
Front liner |
High-chrome alloy A05, A07, A49 |
Rubber | ||
4 |
Rear liner |
High-chrome alloy A05, A07, A49 |
Rubber | ||
5 |
Liner |
High-chrome alloy A05, A07, A49 |
6 |
Expeller |
High-chrome alloy A05, A07, A49 |
7 |
Shaft sleeve |
3Cr13 |
8 |
Water-seal ring |
High-chrome alloy A05, A07, A49 |
9 |
Shaft |
45#steel quenching And high temperature tempering |
10 |
Bearing housing |
Gray iron |
11 |
Expeller Ring |
High-chrome alloy A05, A07, A49 |
Rubber | ||
12 |
Front casing |
Gray iron or Ductile Iron QT500-7 |
13 |
Rear casing |
Gray iron or Ductile Iron QT500-7 |
14 |
Base |
Gray iron |
15 |
Bracket |
Ductile Iron: QT500-7 |
Drive modes
