Help CenterLY110*33-850 Mono-layer PP/PS Sheet Extrusion Line
Related Products
-
2014 Auxiliary Equipments MachineNegotiableMOQ: 1 Set -
2014 Auxiliary Equipments Plastic Cup Rim Curling MachineUS$ 11,000 - 13,000MOQ: 1 Set
-
2014 Auxiliary Equipments Automatic Side Sent Cup Stacker MachineUS$ 5,500 - 15,000MOQ: 1 Set
-
2014 Auxiliary Equipments Jelly Cup Stacker MachineUS$ 1,000 - 200,000MOQ: 1 Set
-
2014 Auxiliary Equipments Compressor Storage Tank Air MachineNegotiableMOQ: 1 Set
Specifications
The machine mainly uses in manufacturing PP,HIPS,PS,PE foil and other packing material for vacuum forming industries.Function
The machine mainly uses in manufacturing PP,HIPS,PS,PE foil and other packing material for vacuum forming industries.
It is featured in good mould ability due to the large L/D ratio of the screw in the extrusion unit.
The machines use advanced hydraulic pressure high speed net changing fitting without stopping the machine, so the operation is convenient, the function is excellent and it can improve.
The mold of head inside is featured in easy mould adjusting, equal sheet thinness, constant flowing speed, high hot utilization, energy saving and so on..
Sheet cutting machine can auto-work such as cutting into slices with settle length, counting number by adopting the micro-computer and laser-pressed control.
The thickness of the foil is controlled by air cutter.
Main Technical Parameter:
Model |
LY110×33-850 |
Material Used |
PP,PS,HIPS,PE |
Sheet Width |
≤850mm |
Sheet Thickness |
0.15-0.8mm |
Layer |
1 |
Extrusion Capacity |
≤200Kg/h |
Screw Dia. |
110mm |
Roller Dia. |
500mm-1pc |
Motor Power |
55KW |
Overall Power |
120 KW |
Overall Dimension |
12.0*1.8*2.2 |
Weight |
7.0T |
Power Supply |
380V/50HZ, Tri-phase, Four-wire |
