PENGPU 140HP Bulldozer PD140-3
Parameters
PD 140-3 bulldozer equipped with wet type main clutch, features:
1. All engine power can be transmitted directly to transmission, and there is no slip once clutch engaged.
2. A thorough and quick disengagement.
3. A smooth engagement for reduced impact during machine starting;
4. Less rotation inertia of the driven part of the clutch for reduced impact to the gears when gear shifting and an easy gearshift.
5. Long lifetime
6. Control easily for reduced operator fatigue
Gearbox
1. The mechanical powertrain means high efficiency of power delivery, rapid gear shift, long gear life and a more reasonable machine structure.
2. It is the transmission with three shafts that make the speed shift by teeth mesh of gears.
Final Drive
1. Double reduction for a reasonable structure and excellent reliability.
2. Reasonable structure and efficient power delivery.
3. High transmit ratio for reduced load on power transmitting components and steering clutch.
Quality Assurance and Warranty
We provide a year or 1500 hours warranty after the date of the delivery to the end-users, (whichever expires first)
| Item | Data | |||
| Weight(kg) (with straight-tilt blade and ordinary cab) | Operating Weight | 15500 | ||
| Ground Pressure (MPa) | 0.062 | |||
| Engine | Model | Shanghai Diesel Engine D9-160 | ||
| Type | Inline vertical, Six cylinder, Water cooling, | |||
| Rated Speed (r/min) | 1700 | |||
| Net Flywheel Power (kW) | 103 | |||
| Min Fuel Consumption Ration (g/kW.h) | 225 | |||
| Travel speed (km/h) |
Forward | 1st | 2.72 | |
| 2nd | 3.88 | |||
| 3rd | 5.83 | |||
| 4th | 8.42 | |||
| 5th | 11.72 | |||
| Reserve | 1st | 3.27 | ||
| 2nd | 4.66 | |||
| 3rd | 7.00 | |||
| 4th | 10.09 | |||
| Power train | Main clutch | Wet type, Multiple disc, Non-constantly engaged | ||
| Transmission | Spur gears, Splash lubricated, 5 speeds for forward and 4 speeds for reverse | |||
| Bevel Gear Shaft | Helical bevel gear, Splash lubricated | |||
| Steering Clutch | Dry, multi-disc, hand-operated with hydraulic booster. | |||
| Steering Brake | Dry, brand brake, foot-actuated | |||
| Final Drive | Double spur gear reduction, splash lubricated. | |||
| Undercarriage | No of track shoe | 37, each side | ||
| No of track roller(each side) | 5 ( 3 single, 2 double) | |||
| Track type | Assembled, Single grouser | |||
| Track width(mm) | 500 | |||
| Track shoe pitch(mm) | 203 | |||
| Work Equipment | Blade Type | Straight Tilt Blade | ||
| Width x Height (mm) | 3200 x 1130 | |||
| Max. Lift above Ground (mm) | 880 | |||
| Max. Drop below Ground (mm) | 360 | |||
| Pitch Adjustment | 53 (degrees) | |||
| Max. Tilt (mm) | >=300 | |||
| Blade Capacity (m3) | 4.1 | |||
| Ripper Type | 3- Shank | |||
| Max. Dig below Ground (mm) | 540 | |||
| Max. Lift above Ground (mm) | 320 | |||
| Weight (kg) | 1528 |
|||
Detail Pictures
Packaging&Shipping
Certificate
Cooperative Factories
Any questions, please feel free to contact me.
