200m Depth! Crawler Type HF200Y Crawler DTH Drilling Machine, Crawler Powerful Well Drilling Rig
US$ 30,000 - 60,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
HF
Model Number:
HF200Y
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sale in South America, Durable HF300Y Crawler Water Well Drilling MachineUS$ 10,000 - 70,000MOQ: 1 Set -
Hot Sale in South America, Durable HF300Y Crawler Borehole Drill MachineUS$ 10,000 - 70,000MOQ: 1 Set
-
Hot Sale! Max 600m Depth! HF-3 Hydraulic 600m Depth Trailer Borehole Drilling RigUS$ 1 - 50,000MOQ: 1 Set
-
Powerful & Stronger!!! HF130 Trailer 130m Multifunctional Drilling EquipmentUS$ 1 - 10,000MOQ: 1 Set
-
Powerful & Stronger!!! HF130 Trailer 130m Multifunctional Drilling MachineUS$ 1 - 10,000MOQ: 1 Set
Place of Origin
Henan, China
Brand Name
HF
Model Number
HF200Y
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Crawler Powerful Well Drilling Rig1. max depth:213m, diameter is127-254mm
2. good at drilling rocks
3. cralwer type, strong
Crawler Powerful Well Drilling Rig
HF-200Y Crawler DTH Drilling Rig
Bore diameter |
127-254mm |
Bore depth |
213m |
Work pressure |
1.05-2.46Mpa |
Air consumption |
16-30m3/min |
Drill rod length |
3m |
Drill rod diameter |
76mm |
dimension |
5800*2040*3200 |
Climb ability |
25degree |
Walking speed |
2.5km/h |
Total weight |
8T |
Main volume system | |
Hoist force |
3400N |
Speed up |
50m/min |
Speed down |
96m/min |
Feed system | |
Axial pressure |
40820N |
Hoist force |
68040N |
Slow lift |
8m/min |
Slow forward |
16m/min |
Quick lift |
26m/min |
Quick forward |
48m/min |
Rotation torque |
3200NM |
Rotation speed |
130r/min |
