Home > Computer Products > Industrial Computer & Accessories > Industrial Computer > Mini Car PC With DVR Function/ Intel 945 GM/Intel Core 2 Duo CPU/1.5GHz

Mini Car PC With DVR Function/ Intel 945 GM/Intel Core 2 Duo CPU/1.5GHz

Name: Mini Car PC With DVR Function/ Intel 945 GM/Intel Core 2 Duo CPU/1.5GHz
Brand: Delong
SKU: 101848683

US$ 270 - 280 MOQ: 10 Pieces

Key Specifications

Products Status:

Stock

Type:

Embedded Computer

Brand Name:

Delong

Shenzhen Delonghuale Electronic & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or Hongkong

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Type Embedded Computer

Brand Name Delong

Model Number DL012PC

Place of Origin Guangdong, China

Specifications

mini car computer pc
low consumption
fanless desigh
intel core 2 duo cpu
DVR function

Mini computer car pc / intel core 2 duo cpu / 1.5GHz

DVR function / fanless desigh

Low consumption

fan view

full view

ports view

Side view

Main specifications

MAINBOARD SPECIFICATION	intel CLIA GMRT-Series Mini-ITX Mainboard Specifications
	Model Name	CLIA GMRT15000
		CLIA GMRT12000
	Processor	1.0GHz intel P-M Processor
	Chipset	intel 855GM
		intel FW82801DB South Bridge
	System Memory	1 DDR 266/400 DIMM Socket
		Up to 1GB Memory Size
	VGA	Integrated intel 855gm AGP Graphics with MPEG-2 Decoding Acceleration
	Expansion Slots	1 PCI
	Onboard IDE	2 UltraDMA 133/100/66 Connectors
	Onboard LAN	RTL8100BL GLAN Controller
	Onboard Audio	ALC202A AC'97 Codec with 2-channel Support
	Onboard TV Out	CH7009B-T TV Encoder
	Back Panel I/O	1 PS2 mouse port
		1 PS2 keyboard port
		1 Serial port
		1 VGA port
		1 RJ45 port
		2 USB 2.0 ports
		1 RCA port (S/PDIF or TV out)
		1 S-Video port
		3 Audio jacks: line-out, line-in and mic-in (Horizontal, Smart 5.1 Support)
	Onboard I/O Connectors	2 USB connector for 4 additional USB 2.0 ports
		1 LVDS Connectors
		3 Serial port connector for a second com port
		1 SIR pin header (IrDA 1.0)
		2 Fan connectors: CPU/Sys FAN
		ATX Power connector
	BIOS	Award BIOS
	Operating System	Windows 2000/XP, Linux, Win CE/XPe
	Operating Humidity	0% ~ 95% (relative humidity; non-condensing)
	Form Factor	Mini-ITX (6 layers) 170mm*170mm
OTHER INFORMATION	RAM	512MB
	disk driver	80G 2.5inch mini disk
	power supply	supply delay shutdown time and start time
Accessories	1pcs Stand Shelf
	1pcs Instruction Manual
	1pcs CD Drive
	Some Screw for Fixing the Shelf
