electric sliding cold room door
cold store for fresh meat storage
|
|
cold store for fresh meat storage
Polyurethane foam is been sandwiched between the two outer skins and hence is known as PU sandwich panels. We are engaged in manufacturing reliable PU sandwich panels in variegated specifications.. Those two layers are available i profile with zinc coated, galvanized steel, embossed aluminum, stainless steel or other material sheets. |
|
|
|
Our panels are 960mm width, in a range of thickness with 50mm, 75mm, 100mm, 120mm, 150mm, 200mm and up to 12 meters length. Different cold room has different temperature so need use different thickness insulation panel: |
Cold room temperature |
Thickness of panel |
5~15 degree |
75mm |
-15~5 degree |
100mm |
-15~-20 degree |
120mm |
-20~-30degree |
150mm |
Lower than -30degree |
200mm |
Dimension |
Length (m) *Width (m)*Height (m). customized |
Panel |
polyurethane insulation panel,38~42kg/m3, fire resistance |
Foaming material |
Polyurethane |
Panel thickness |
75mm,100mm, 120mm,150mm,180mm,200mm optional |
Steel cover |
stainless steel plates,color steel plates and embossed aluminum plates |
Panel connection |
cam lock type, use hexagonal key to assemble and disassemble |
Type of door |
hinge door, sliding door |
|
Temp.of cold room |
-45~+20°C degree, optional, can be mixed temp in a project. |
Refrigeration unit |
Bitzer, Copeland, Maneurope (Danfoss),etc. |
Refrigeration type |
air cooled / water cooled, R134a, R404a, R507a or R22 |
Fittings |
all necessary fittings are included, optional.. |
Place to assemble |
indoor/out door(concrete construction building/steel construction building). |
Voltage |
220V/50HZ, 220V/60HZ, 380V/50HZ optional. |
Functions |
fresh-keeping, freezing, quick-freezing, fire-proof, explosion-proof, air-conditioning are all available. |
Other accessories: world-famous brands, like Danfoss, Castle, Every Control, Siemens, LG
|
| Refrigeration fair |
|
| Customer visit for cold store for fresh meat storage |
|
|
1) What’s the products do you want to store in this cold room? 2) Could you provide the detailed inside dimension of this cold room?(m) 3) Which kind of door do you prefer,Sliding type or hing type? Color steel or stainless steel? 4) How many tons of products will be put in cold room per once(ton/once)? 5) What’s the required temperature inside the cold room(°C)? 6) What’s the voltage/phase/frequency in your place? We can do customized dimension according to customers'requirements. We have access to all the leading Cold Room refrigerators brands and can offer independent advice, and recommend the right equipment to meet your business requirements. |
