Specifications
1,three phase noise filter2,a variety of optional connection mode
3,electrical noise filter
4,high quality best price
QXLB31045 10A ac line power three phase noise filter
ac
characteristics and application |
1. the safety and reliablity; |
2 .excellent differential mode and mode interference suppression ability; |
3. wide current range:0.5A - 100A; |
4 .ease of use and umber of optional connection mode; |
5. be suitable for switching power supply, UPS power, instrumentation and electronic equipment under 220V AC |
|
Basic technical parameters |
Rated current : 0.5A - 100A; |
Rated voltage:0-250 V, (50 hz AC) |
|
Leak electricity flow: working current: Less than 25A ≤0.5 mA;More than 25 A be equal or greater than 1 ma |
Insert Loss:be equal or greater than 30dB (1∼30MHz) |
Insulation voltage: 2300V (AC line to ground, 1 minute) |
1500V (DC, line for line, 1 minute) |
Insulation resistance :be greater than 50MΩ ( 500VDC, 1minute) |
Environment temperature :- 25°C~ + 85 °C |
Constant damp heat : 40 °C 93% |
In order to meet customers special requirements, our company also generate DC and other non-standard design and production of power supply filter.
Specifically for customers design and production of power supply filter, and product model with the letter Z finally named.
