Help Center7" LCD Screen 3 in 1 Almighty CCTV Tester in IP +AHD +CVBS Security Camera Tester Video CCTV Test Tester
Related Products
-
Professinal 4D Joystic Control Video Conference Camera VISCA Keyboard Controller PTZ Dome CameraUS$ 1 - 185MOQ: 1 Piece -
PTZ Camera 3D Keyboard Controller High Performance CCTV Security CameraUS$ 49 - 78MOQ: 1 Piece
-
Onvif 4D Joystick PTZ IP Network Camera Keyboard Controller LCD Display Support Dahua ip CameraUS$ 212 - 240MOQ: 1 Piece
-
8" TFT-LCD 3D PTZ Keyboard Controller Dispaly With Big Scren Monitor for Speed Dome Quality ChoiceUS$ 165 - 189MOQ: 1 Piece
-
LCD Display 3D RS485 PTZ Keyboard Controller for PTZ Camera Joystick For SecurityUS$ 72 - 99MOQ: 1 Piece
1. 7 inches full view IPS HD screen resolution of 1280 × 800, PPI up to 216
2.Backlight display brightness adjustable up to 500cd, display contrast 800: 1
3.Adopt G + G structure capacitive touch screen , hard wear-resistant , corrosion-resistant, high transmittance
4.NTSC / PAL analog CVBS video image display , scaling , video recording , photograph
5. 10 / 100M Ethernet interface , built-in 150M WIFI wireless function
6. ONVIF IPC extreme speed test, image display for click,convenient and effective. Support camera parameter modification.
7.support H264 / MPEG4 / MJPEG format IP camera test , maximum resolution UP to 1080P
8.IP address scan intelligent recognize IP camera address, support subnet one key modification..
9.support display ONVIF network camera image and modify parameters
10.Support network cameras privite protocols test of multiple manufacturers such as Hikvision, DAHUA , ACTI, NCR , can be customized to add
11.Support PELCO-P, PELCO-D, SAMSUNG etc 30 kinds of PTZ control protocol
12. support high-definition video images in real time zoom , maximum zoom up to 5x
13. Internal SDCARD 8G storage space , removable external MicroSD card
14.Built CVBS color bar output function, can be used to test and debug the monitor
15. IP address scan function , you can quickly search the IP camera address
16. PING function, to test the network connection status of the target IP address.
17.PoE voltage test , test PoE switch power supply status
18. PoE 48V / 24W standard power supply output, supplies power to the PoE camera
19.DC12V / 2A output , self-recovery short-circuit protection , provide power for a variety of cameras including PTZ
20.Audio input test and recording, can test audio signal
22.bright white LED, convenient for using in dark area
23. HDMI high-definition image output , support 1080P 60fps
24. 7.4V 5000 mAh high-capacity polymer lithium battery , once charge 5 hours, can use continuously for 12 hours.
product model |
700 Almighty CCTV Tester |
touch screen |
7 inch G + G structure capacitance screen |
LCD screen |
7-inch resolution of 1280 × 800 IPS fule view |
Ethernet port |
10 / 100M adaptive |
WIFI |
Built-in WIFI, speed 150M |
IP camera Test |
ONVIF speed test, one second scan,click display viedo support maximum 1080P H264 / MJPEG / MPEG4 format, support for modify IP, support ONVIF PTZ control |
CVBS analog camera test |
1 channel CVBS analog input , support PAL / NTSC standard adaptive |
Video image enlarge |
Real-time enlarge mobile HD video image , maximum to 5 times |
Photograph, video playback |
Supprot video record and All video formats. Support H264 coding storage |
Audio Test |
One channel audio input test , can be recorded and saved , one audio output for connecting headphones |
PTZ control |
Supports Pelco-D / P, Samsung, Panasonic at30 kinds of protocols. |
Color Bar Generator |
can send PAL / NTSC color graphics section |
DC 12V power output |
12V DC output , the maximum current 2A, supply power for camera |
PoE power output |
48V PoE standard output , to provide power for the PoE cameras |
RS485 serial tools |
Send or Recive any data or hex data |
PSE voltage test |
display PoE power supply device voltage and circuit conditions |
HDMI video output |
Send high-definition monitor images to HDMI Monitor |
DC 5V Output |
Provides power forthe USB-powered camera or cellphones,maximum 2A |
Charger |
DC 12V / 2A |
Battery |
Built-in 7.4V lithium polymer battery , capacity 5000mAh, can provide power for 8-16 hours |
Language |
Chinese Simplified , Chinese Traditional, English |
Internal SD storage |
8G |
Operating temperature |
-10℃--+50℃ |
Working humidity |
30%--90% |
size |
23cm*14cm*4.5cm |
Weight |
0.9kg |
OEM Service:
We could offer OEM and ODM services for our clients.
Delivery Time:
Sample order 3-5 working days, bulk order 7-15 working days.
Quality Warranty:
2 years for free repair. Whole life service for continue cooperating customers!
Price Term:
EXW Shenzhen
Delivery Term:
By Express(DHL/FEDEX/TNT/UPS/EMS/CHINA POST),By air,By Sea.
1. About the sample: How could I get a sample?
Once receive your payment for samples and their express delivery and then send samples
to you. The prices of the samples are the same as those on the pricelist. Express delivery
charge depends on the quantity of the samples.
2. About price list: can I get your price list?
Yes, please tell us the products (with their code number) and order quantity, then we will
offer the price by e-mail. And our price list will keep updated every month.
3. About the shipment: what type of shipment will you use?
We usually ship the products by express delivery to your door or by air freight to your nearest
airport. If the order quantity is large, we may ship by sea container.
4. About payment: what terms of payment do you use?
We accept TT (Telegraphic Transfer,MoneyGramor Western Union as payment term for small
order and L/C for larger order.
5. About the MOQ: What is your minimum order qty?
Our minimum order qty is 20pcs each model, but we accept small order as trial order.
6,About compensation: what is your company's compensation policy?
We can compensate buyer's loss if our products have quality problem. For small qty
problem products, we can replace with new products in next order. For larger qty problem
products, we can accept returned problematic products, then we check them and replace
them by good quality products.
7. About sole-distributor: How can I be your sole-distributor?
We have special policy for sole-distributor. Please contact our sales person to get related files.
8. About OEM: could we place order by OEM style to produce our own brand products in China?
Of course you can. Welcome to do OEM.
If any further problem, welcome to contact our sales person.
Thank for your interest.
