Three Rollers Grinder-----SG Series Three Roll Mill

Three Rollers Grinder-----SG Series Three Roll Mill thumbnail-1
Three Rollers Grinder-----SG Series Three Roll Mill photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Additional Capabilities:
Milling
Place of Origin:
Zhejiang, China
Brand Name:
HUPC
Contact Supplier Request Quote Chat Now
HUPC Chemical Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Additional Capabilities Milling
Place of Origin Zhejiang, China
Brand Name HUPC
Model Number Mill

Specifications

Complete machine of three rollers grinder this series is welded by high quality steel plate



three rollers grinder-----SG series Three Roll Mill


Complete machine of three rollers grinder this series is welded by high quality steel plate.The transmission gear adapts oil-immersed type and the operative handwheel is transmitted by gear.It features beautiful appearance,convenient to operate,long life and so on.Particularly it is suitable for grinding the product that has high dispersive viscosity and fine size.

Parameter       Model

SG6

SG9

SG12

SG16

SG16Extra

Roller diameter(mm)

150

260

305

406

406

Length of roller (mm)

300

675

760

810

1000

Distance from discharge hole to ground(mm)

660

580

650

820

820

Roller rotating speed(r/min)

Low speed roller

34

23

15.8

14

14

Medium speed roller

78

64

47.4

43

43

High speed roller

181

183

142

130

130

Main Motor power (kw)

3

7.5

11

15

22

Overall dimension (mm)(L x W x H)

980*750*915

1200*1000*1100

2560*1735*1510

2560*2035*1525

2760*2035*1525

Machine weight(kg)

500

2000

3800

5300

5800

Packing dimension (mm) (L x W x H)

1000*1000*1250

1900*1500*1600

2100*1900*1950

2300*2000*1950

2600*2050*1950
