European style villa / simple light steel structure villa house
Reference layout plan
| Light steel structure villa house Materials list | |||
| A | Light Steel structure | ||
| 1 | Cold-formed Aluminum coating steel | kg | AZ150,G550 |
| 2 | Accessories of steel structure | m2 | SGC440,Z275 |
| B | External wall system | ||
| 1 | Fiber cement wood grain board | m2 | 3000mm*210mm*8mm |
| 2 | Vapor barrier | m2 | |
| 3 | OSB board | m2 | thickness:12mm |
| 4 | Wall fiber glass insulation | m2 | 100mm, 16kg/m3 |
| 5 | Gypsum board (inside of external wall ) | m2 | 2400mm*1200mm*12mm |
| 6 | Dry finish | m2 | |
| 7 | Waterproof material | m | 1.2mm |
| C | Internal wall system | ||
| 1 | Gypsum board | m2 | 2400mm*1200mm*12mm |
| 2 | Fiber cement board (kitchen and bathroom) | m2 | 2440*1220*10mm |
| 3 | Wall fiber glass insulation | m2 | 100mm, 16kg/m3 |
| 4 | Dry finish | m2 | |
| D | Roof & Ceiling system | ||
| 1 | Steel roof | m2 | Colorbond |
| 2 | Zinc metal tile battens | kg | |
| 3 | Waterproof material | m2 | 1.2mm |
| 4 | OSB board | m2 | thickness:12mm |
| 5 | Roof fiber glass insulation | m2 | 100mm, 16kg/m3 |
| 6 | Gypsum board for ceiling | m2 | 2400mm*1200mm*12mm |
| 7 | Cornice and kitchen and bathroom ceiling | m2 | 0.5mm K-140 steel panel |
| 8 | Steel gutter system | m | |
| E | Doors and windows | ||
| 1 | Exterior safety door | m2 | |
| 2 | Interior MDF door | set | |
| 3 | Aluminum glass sliding door | m2 | Australian Standards |
| 4 | Aluminum glass windows | m2 | Australian Standards |
Light steel structure
Interal system the light steel structure villa house
Inside finishing the light steel structure villa
All the structure, walls and roof system can be prefabricated in our factory before delivery !
FAQ
1 . How much time and how many people are required to complete the project with the building system of DreamHouse ?
1.1 . Villa: The construction period varies depending on the size and design. For a villa of 150m ² : 10 days are required for the basic structure and 20 days for decorating with 5 technicians .
1.2 . Mid-size building (home , hotel, office , schools , clinics, etc. ..)
For a 4-storey building with an area of 1500m ² , 20 days are required to complete the basic construction and 10 days for decoration. The number of technicians required is 20.
1.3 . Steel structure warehouse (factory, workshop , showroom , etc. ..)
Construction time varies depending on the size , the plan and the professional skills of workers. A warehouse of 1000m ², 10days is required for installation and 20 people for the implementation .
1.4 . Other buildings (bungalows, container house , temporary dormitory , etc. ..)
Construction time : 2 days
Number of Technicians: 4
2 . How long does it take to produce a constructive system?
Generally, 30 days are required to produce a villa or a steel structure building steel structure warehouse or after confirming the architectural level. This is indicated in the quote
3 . How many containers required for my project ?
After confirmation of your request , we send our shipping calculateation weight and overall dimensions of all building materials breakdown. After the calculation, we send you our answer.
In general, a 40-foot container is required for the transport of a building with an area of 100m2 house.
4 . What are the mandatory information to send you to get a quote?
After receiving your first inquiry, we will send you a complete array that contains all the information we need.
5 . How to ensure that the structure meets the criteria for local buildings ?
Our structures are in line with national and European standards ( Eurocodes 8 TSR ) . We use the latest building technologies and calculations are made according to the rules of art. Finally, an auditor certifies each office building after an on-site inspection .
6 . How to become agent of your company?
First of all, thank you for your interest in our company. Generally , we take as agents that customers who bought our products at a given quantity .
After receiving your request, we will take it into consideration and make a careful assessment .
7.Are your buildings resistant to hurricanes and earthquakes?
Ideally , the process of construcion based modular steel frames has been developed in Japan to address critical environmental conditions . The strength of steel and modular construction allow the absorption of large loads generated during disasters.
Buildings withstand earthquakes of level 7 on the Richter scale and cyclone with sustained winds up to 100km / h.
8. Do the houses have warranty?
If the goods are damaged in transit , or the house without problems in the case of external damage , we will send you the new goods in the next order. In this case, you can save the sea freight !
