Help CenterMobile Phone Glass Lens Anti Scattering Film Coating Device
Related Products
-
High Pricision Automatic Optical Glass Explosion Proof Sheet Attaching MachineUS$ 1 - 48,652MOQ: 1 Set -
Mobile Phone Resistive Touch Screen Anti Scattering Film Fixed MachineUS$ 1 - 48,652MOQ: 1 Set
-
Smartphones Capacitive Touch Screen Film Automatic Laminating MachineUS$ 1 - 48,652MOQ: 1 Set
-
High Precision Sensor Glass Anti Explosion Sheet Attach MachineUS$ 1 - 48,652MOQ: 1 Set
-
Mobile Capacitive Touch Screen Explosion Proof Sheet Stick MachineUS$ 1 - 48,652MOQ: 1 Set
Specifications
coating film machine1,laminate film on screen of mobile phones,digital products
2,high precision,high stability
3,no bubble
Key Features:
1,The machine is special research and development for sticking the protective film,explosion-proof film, polarizing film with hign precision on mobile phone screen, tablet PC, car navigation etc.
2,Adopting photoelectric sensor and servo motor to achieve XY direction high precision automatic proofreading, to ensure that the sticking process location accuracy.
3,Using the unique mechanism to achieve no bubbles.
4,The machine Mainly includes PLC, servo motor, precision mechanical hand, sticking film mechanism, feeding mechanism,material receiving mechanism, human-machine interface, FFU filtering devices and other components, has been widely used in flat panel display industry.
Technical Specifications:
| The efficiency of sticking | 10~20pcs/min |
| Sticking accuracy | ± 0.05mm |
| Maximum stick size | 2.5~5.0 inches |
| Correction methods | XY correction |
| Stick results | smooth,without folds,no bubble |
| Work cleanliness | class 100 and high efficiency FFU (optional) |
| Working voltage | AC220V/50Hz |
| Gas supply pressure | ≥ 0.4Mpa |
| Weight | about 450Kg |
| Machine dimension | 950(L)*850(W)*1720(H)mm |
Main performance:
1, using the PLC program and the high precision servo system control, reliable operation, stable performance, high precision position control.
2, the clear and intuitive interface, easy human-computer dialogue mode, convenient for various models of the settings and change.
3, laminating roller pressure is reliable, and with high precision micrometer tracking confirmation.
4, the machine adopts SMC pneumatic components and delta high precision servo control system.
5, equipment with high precision servo motor cross correction, to ensure the accuracy of the location of the glass.
6, the main components imported aluminum alloy, precision machining, grinding processing, ensuring the hardness and smoothness.
7, equipment mainly uses the Japan Keyence sensor and Germany the Leuze ultrasonic sensor.
8, equipment with automatic feeding and automatic film tearing blanking function.
