Help CenterTouch Screen Film Processing Machine
Related Products
Specifications
It's mainly used for sticking protective film and riot film on the screen of mobile phones, GPS, handheld computer etc.Key Features:
1,The machine is special research and development for sticking the protective film,explosion-proof film, polarizing film with hign precision on mobile phone screen, tablet PC, car navigation etc.
2,Adopting photoelectric sensor and servo motor to achieve XY direction high precision automatic proofreading, to ensure that the sticking process location accuracy.
3,Using the unique mechanism to achieve no bubbles.
4,The machine Mainly includes PLC, servo motor, precision mechanical hand, sticking film mechanism, feeding mechanism,material receiving mechanism, human-machine interface, FFU filtering devices and other components, has been widely used in flat panel display industry.
Specifications:
1,The efficiency of sticking :10~20pcs/min.
2,Sticking accuracy: ± 0.05mm
3,Maximum stick size: 2.5~5.0 inches
4,Correction methods: XY correction
5,Stick results: smooth,without folds,no bubble
6,Work cleanliness:class 100 and high efficiency filter (optional)
7,Working voltage: AC220V/50Hz
8,Gas supply pressure: ≥ 0.4Mpa
9,Outline dimension:950(L)*850(W)*1720(H)mm
10,Weight: about 450KG
