Place of Origin Taiwan, China
Main Raw Material Other
Usage Other, High temperature corrosion prevention coating
Application Method Spray
State Liquid Coating
Brand Name Rainbow paint
Model Number No.1566

Specifications

1.HIGH TEMPERATURE COATING
2.Using for CUI system





Product Description







PRODUCT NUMBER

 No.1566

TYPE

High temperature corrosion prevention coating based on inorganic copolymer with



heat-resisting and corrosion resistant pigments.



USES

Used for metal structures such as steel pipes, steam pipes, hot oil pipes, plant facilities



etc.















CHARACTERISTICS

1. Excellent high heat resistance, can withstand heat up to 650℃.



2. Dry-hard within 8 hours (25℃), paint film can reach 80% cured in room temperature,



when applying temperatures are above 60℃, paint film can be cured completely after



3 days.















3. Can be sprayed directly to high temperature carbon steel and galvanized steel ,



stainless facilities when the temperature up to 220℃.





4. Excellent anti-corrosion for thermal shocking structures.



5. Excellent adhesion and corrosion prevention.





6. Good moisture resistance for the condition of hot and cold cycle, suitable for CUI



environment.











COLOR

Iron-gray , Silver-grey











WEIGHT

Above 1.6 kg/L











VISCOSITY

Above 70 KU (25℃)











DRYING TIME

Set-to-touch

2 hrs.

Dry hard

8 hrs.   (25℃)

Transportable time  24 hours

FULLY CURED TABLE

Under 60℃  7 days (Paint film reached 80% cured.)





60 ~ 100℃

above 3 days











100 ~ 150℃ above 1 day











150 ~ 200℃ above 1 hour









OVERCOATING INTERVALS

Substrate temperature (25℃):

4 hours (minimum)





Substrate temperature (50 - 80℃):

1 hour (minimum)





Substrate temperature (81 - 120℃):



30 minutes (minimum)



Substrate temperature (120 - 220℃):

10 minutes (minimum)



No time limit of maximum overcoating intervals.



OPTIMUM FILM THICKNESS

Wet

196 ~ 294 microns

Dry



100 ~ 150 microns

TOTAL FILM THICKNESS

Dry

300 ~ 500 microns









THEORETICAL COVERAGE

19.3~12.9 m2/Gal

5.1~3.4 m2/L

3.1~2.1 m2/Kg   (Dry: 100 ~ 150 microns)

VOLUME SOLIDS

Above 51%













THINNER AND THINNING RATE

Applying temperature: Room temperature~100℃: 10 ~ 20% 1564X  (MAX. 129℃)



Applying temperature: 101~150℃:

20 ~ 35% 1564S





Applying temperature: 151~220℃:

35 ~ 50% 1564S



STORAGE SHELF LIFE

Minimum 6 months under normal storage conditions.



APPLICATION METHOD

Air spray, Airless spray
