Specifications
medical oxygen regulators gaugesAluminum body all brass inner core
Barb or DISS outlet
Output:50 PSI
- oxygen flowmeter
- origial factory OEM
- CE;ISO9001ISO13485
- Kind standards opional
An oxygen flow control regulator is a pressure-reducing device, which lowers the oxygen pressure from a cylinder to levels, which can be safely used by the patient. Oxygen Regulators are intended for the administration of oxygen to patients who need increased oxygen levels to improve their breathing conditions.
This oxygen regulator uses an advanced, patented Intelliflo disc to regulate oxygen flow down to 1/32 LPM with very tight tolerances. Featuring a brass core for maximum safety and permanent laser etchings on knob and body that won't peel, flake or wear off. All metal anodized aluminum construction is more durable than plastic and will not rust, plus the gauge protector helps prevent damage. Five-year warranty (excludes contents gauge and gauge protector). 1/2 to 15LPM Small Tank Regulator.
Materials of Construction
Brass: Inlet retainer, Relief valve, Piston, Rotor,Flow control housing, Barb outlet
CGA 870: Ergonomic-Grip T-handle, Inlet filter, Retainer, Brass/ Viton Washer seal
Aluminum: Body, Barb outlet, Clearly Anodized
Silicone: O-rings
Sintered Bronze: 40 Micron inlet filter
Body Finish: Green Anodize, Laser Etched markings
Diameter: 1 3/8” Nominal
Full-Length: 5 3/5” approximately
Weight: 416g
Gauge: Ø1.4” 0-3000 PSI, Clean for O2 service, UL listing,
Boot, 1/8” NPT, Fill/Refill
Knob: Easy-click, groove-grip with recessed adjoining body area, allow for easy flow adjustment.
Flow Window: for accurate, confusion-free flow settings, 0-4, 0-8, 0-15, 0-25lpm,
Exterior Markings: Company Logo, Model No., Description,“Made in China” and “Use No Oil” text
Packaging and Labeling: Box to be 7.7” x 3.0” x 3.0”, Label matching Current article.
