Help CenterHot Sale Medical Oxygen Regulator DY-C5A
Related Products
-
Hot Sale Oxygen Regulator Medical DY-C5US$ 10 - 15MOQ: 120 Pieces -
Hot Sale Medical Oxygen Regulator (DY-C3 )US$ 9.2 - 11.2MOQ: 500 Pieces
-
Brass Body of Pressure Medical Oxygen Regulator(DY-C6 B)US$ 10 - 10.3MOQ: 500 Pieces
-
High Quality Medical Oxygen Regulator(DY-C5 C)US$ 9.2 - 11.2MOQ: 500 Pieces
-
Brass Body of Pressure Oxygen Regulator(DY-C7B)US$ 10 - 10.3MOQ: 500 Pieces
Specifications
medical oxygen regulator
Input pressure:15mpa
Output Pressure:0.2mpa-0.3mpa
Control Pressure of Safety Valve:0.35±0.05mpa
Main feature
1.The product has artistic outlook,and flow comfortable and stable
2.The intemational standard connect way,is suitable for all kinds of gas bottle installtion
3.Intemal reseating relief valve protects against overpressurization
4.All series have passed and CE certificate
More details
The main part uses goodness brass and cut with precision digitally contrlled lathe
Lengtening are inlet valve lever fit for the different capacity of oxygen cylinder
Integrated casting flowmeter
Flow tube,wet cup of high-pressure sterilized Humidification body to meet european standards for B-level disinfection
The maximum temperature of 121 degree pressure 0.142mpa
Our Innovatio
1. Body Material:brass chrome plated
2. Easy to read dual scal gauge with screw-on polycarbonate lens for durability.
3. Precision engineered pressure compensated design flowmeter for precise flow.
4. Flowmeter with easy to read tube and virtually unbreakable transparent polycarbonate outer cover for strength and 360 visibility
5. sintered metal inlet filter to trap impurities
6. Reliable external safety relief valve
7. Flush feature permits emergency oxygen to 40LPM.
8. Please inform inlet and outlet thread when ordering.
Product Display
How to use
1. Open the valve of oxygen cylinder after connect the screw nut of air intake closely.
2. Connect the oxygen pipe to the oxygen outlet firmly.
3. Demount the humidifying cup(anti clock wise rotation), put some distilled water in (purified water or plain boiled water can also take place), the water quantity should be between the bottom and top tick mark, then tighten up the bottle cap to the humidifying cup(clockwise rotation).
4. Rotate the flow regulating valve to the rate you need (anti clockwise to up, clockwise to down, till to close), then put it to nose to use.
5. Close the valve of oxygen cylinder firstly while not using, then close the flow regulating valve until the pointer of oxygen manometer return to zero.
Attention
1. Make sure there is no ash on the connector and check the screw thread, then install the inhalator.
2. Make sure the flow meter is vertical to the floor and flow regulating valve is closed, then open the valve of oxygen cylinder slowly, regulate the flow after the high pressure gauge shows the pressure of the oxygen cylinder.
3. No drastic shock, far away with the corrosive substance, and no oil stain.
4. The set screw of the safety valve can't be rotated at random, non-professional people are forbidden to dismount.
Condition for storage
Should be kept in the environment whose humidity is less than 90%, no corrosive gas and drafty.
Quality guarantee period
We will fix or change the oxygen inhalator within a half and a year after the day of living the company when it can't proper functioning, it should be under the condition of obeying the rule of storage and using.
Specification
1. Forbid to use the Buoy Type Oxygen Regulator to take oxygen atomization treatment.
2. Forbid to dismount by yourself.
