Rotary Vane Wheel Liquid-sealed Water Saving Type Water Meter LXSJ-15E~50E

Rotary Vane Wheel Liquid-sealed Water Saving Type Water Meter LXSJ-15E~50E thumbnail-1
Rotary Vane Wheel Liquid-sealed Water Saving Type Water Meter LXSJ-15E~50E photo-1
Negotiable MOQ: 500 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Tongqiu
Model Number:
LXSJ-15E~50E
Contact Supplier Request Quote Chat Now
Ningbo Tongqiu Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Tongqiu
Model Number LXSJ-15E~50E

Specifications

Ministry of Construction Popularizing Product, recording by drops

Economic benefits:

Start flowrate of water saving water meter is very low, and it can record by drops. So water saving type water meter can bring the water supply company immeasurable economic benefits. Compared with common water meter, water saving type water meter increases the sensitivity by more than 10.0L/h.

Features :

starting flow≤2L/h, help you recording by drops. Start flowrate of the water meter raises five to eight times compared to the common water meter. It is efficient in preventing leakage and dripping water during water using, which spurs users to repair pipe leakage which is behind water meter, and improve people's awareness of water saving. With one-way valve structure of inlet, you can’t use water normally if the meter is reversely installed. The size ,as same as normal water meter, is convenient for installation.

Working Condition  :

 0.3℃≤Water temperature≤40℃                 0.03Mpa≤Hydraulic pressure ≤1Mpa

Indicating error:

At low zone is ±5% from minimum flow rate(qmin) to transitional flow rate(qt) exclusive boundary ;

At high zone is ±2% from transitional flow rate(qt) to overload flow rate(qs).



Type Nominal caliber       DN            (in.) Length    mm Width       mm height       mm Permanent flowrate Transitional flowrate Minimum flowrate Start flowrate
m3/h m3/h m3/h L/h
B B B
LXSJ-15E 1/2" 165 98 104 1.5 0.12 0.03 ≤2
LXSJ-20E 3/4" 195 98 106 2.5 0.20 0.05 ≤2
LXSJ-25E 1" 225 104 115 3.5 0.28 0.07 ≤3
LXSJ-32E 11/4" 230 104 117 6 0.48 1.2 ≤3
LXSJ-40E 11/2" 245 125 147 10 0.80 2 ≤4
LXSJ-50E 2" 280 125 172 15 3.00 4.5 ≤4



 Rotary Vane Wheel Liquid-sealed Water Saving Type Water Meter LXSJ-15E~50ERotary Vane Wheel Liquid-sealed Water Saving Type Water Meter LXSJ-15E~50ERotary Vane Wheel Liquid-sealed Water Saving Type Water Meter LXSJ-15E~50ERotary Vane Wheel Liquid-sealed Water Saving Type Water Meter LXSJ-15E~50E
