Home > Instruments & Meters > Meter for Liquid & Gas > Water Meter > LXSG15E Remote Dry Dial Brass Water Meter
LXSG15E Remote Dry Dial Brass Water Meter
US$ 5 - 50
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
TQ or OEM
Model Number:
LXSG-15
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
15mm Digital RemotE Dry Dial Impluse Water MeterUS$ 5 - 50MOQ: 500 Pieces -
Multi Jet Dry Dial Plastic Nylon Water Meter LXSG-15~40US$ 2 - 50MOQ: 500 Pieces
-
Rotary Vane Wheel Output Adjustable Dry Dial Iron Water Meter LXSG--15E~50EUS$ 1 - 5MOQ: 500 Pieces
-
Multi Jet Dry Dial Plastic ABS Water Meter LXS-15S~25S Quality ChoiceUS$ 1.8 - 5MOQ: 500 Pieces
-
1/2 Rotary Vane Wheel Wet Dial Iron Water MeterUS$ 2 - 15MOQ: 1000 Pieces
Place of Origin
Zhejiang, China
Brand Name
TQ or OEM
Model Number
LXSG-15
Features :
This is a dry-type water meter.Its counting and measuring devices are driven by magnetic coupling. It is characterized by easy reading,good antifreezing property and ability to permanently keep the reading clear.
Working Condition :
Water temperature: ≤40℃ pressure: ≤1Mpa
INDICATING ERROR:
At low zone is ±5% from minimum flow rate(qmin) to transitional flow rate(qt) exclusive boundary ;
At high zone is ±2% from transitional flow rate(qt) to overload flow rate(qs)
| Type | Meter size Dia DN (in.) | Class | qs Overload Flow | qs Nominal Flow | qs Transitional Flow | Qmin Min Flow | Min Reading Lectura | Max Reading Lectura |
| m3/h | 1/h | m3 | ||||||
| LXSG-15E | 1/2" | A | 3 | 1.5 | 150 | 60 | 0.0001 | 9999 |
| B | 120 | 30 | ||||||
| C | 22.5 | 15 | ||||||
| LXSG-20E | 3/4" | A | 5 | 2.5 | 250 | 100 | 0.0001 | 9999 |
| B | 200 | 50 | ||||||
| C | 37.5 | 25 | ||||||
| LXSG-25E | 1" | A | 7 | 3.5 | 350 | 140 | 0.0001 | 9999 |
| B | 280 | 70 | ||||||
