Screw terminal aluminum electrolytic capacitor 450V 8200UF, Screw type Large can aluminum electrolytic capacitor 450V, 450V 8200MFD Bolt type Electrolytic Capacitor, 8200UF 450V 2000 hours 105C electrolytic capacitor offered by AnXon Electronic
Aluminum Electrolytic Capacitor CD136 Large Can Capacitor
Rated Spec: |
450V 8200uF, 450V 8200MFD |
Tolerance: |
M, ±20% |
Type: |
Screw terminal, Large can, Bolt type |
Load life : |
2000 hours at 105C |
Operating Temperature: |
-40C ~ +105C |
Size / Dimension(ΦD×L): |
D: 90mm, L: 157mm |
Our Advantage :
1. Short lead time, quick delivery
2. Low cost price , great quality
3. 100% convinced by world class customers
4. Custom case size capacitor available
Screw Terminal Large Can Aluminum Electrolytic Capacitor Application Guide
• UPS, Industrial power supply
• Frequency converters, Wind power converters
• Switch-mode power supplies
• Solar inverters
• Professional power supplies
Aluminum Electrolytic Capacitors with screw terminals 10V, 16V, 25V, 35V, 50V, 63V, 80V, 100V, 160V, 200V, 250V, 350V, 400V, 450V, 500V
450V Informations
Series |
Spec. |
Cap Code |
Dimension(mm) |
Load life |
|
D |
L |
||||
|
Screw Terminal Large Can Electrolytic Capacitor
|
450V 2200UF |
222 |
64 |
96 |
105C 2000 hours |
450V 2700UF |
272 |
64 |
115 |
||
450V 3300UF |
332 |
64 |
130 |
||
450V 3900UF |
392 |
77 |
115 |
||
450V 4700UF |
472 |
77 |
130 |
||
450V 5600UF |
562 |
77 |
155 |
||
450V 6800UF |
682 |
90 |
157 |
||
450V 8200UF |
822 |
90 |
157 |
||
450V 10000UF |
103 |
90 |
196 |
||
450V 12000UF |
123 |
90 |
236 |
||
