CK61125 Series Cnc Horizontal Lathe Machine With 6 Tons Load Capacity

US$ 90,717 - 278,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian/Tianjing/Shanghai/Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 1250mm

Place of Origin Liaoning, China

Brand Name LFM

Model Number CK61125 cnc horizontal lathe machine

Voltage Customer's Requirement

Power(W) 22kW

Dimension(L*W*H) depends

Weight depends

Certification CE Certificate; ISO9001:2008; GB/T19001:2008

After-sales Service Provided Engineers available to service machinery overseas

CK61125 cnc horizontal lathe machine

Main Features

Servo main motor 22kW,

X/Z axis servo motor,

automatic 4 gears, infinitely variable speeds within the gear,

Spindle Speed: 3.15~ 315rpm, 4-position turret,

Spindle bore: φ130mm,

Bed width:755mm,

φ1000mm manual 4-jaw chuck, manual tailstock

CE Standard and CE Certificate;

Main Technical Data

Specifications	Unit	Parameter
Swing over bed	mm	1250
Swing over carriage	mm	900
Between distance	mm	2000
Dia. Of chuck	mm	1000
Cutting length	mm	1800
Width of bed	mm	755
Center height	mm	625
Support capacity between centers	kg	6000
Spindle hole through	mm	130
Spindle nose		ISO A2-15
Spindle taper	mm	Metric No. 140
Spindle speed	rpm	3.15~ 315 Manual 21 gears/ automatic 4 gears, infinitely variable speeds within the gear
Turret made by China		4 positions, vertical type
Size of tool holder	mm	32×32
Travel of X-Axis	mm	740
Travel of Z-Axis	mm	1800
Feeding speed of X-Axis & Z-Axis	mm/min.	X: 1 ~ 2,000 Z: 1 ~ 2,000
Rapid traverse of X-Axis & Z-Axis	mm/min.	X:4000Z:6000
Travel of tailstock quill	mm	300
Taper of tailstock quill		Metric No. 80
Rapid speed of tailstock	mm/min	3000
Controller		FANUC 0i mate /FANUC 0i-T
Servo motor	Nm	30 ( for X-Axis) 38 ( for Z-Axis)
power of main servo motor	kW	AC 22
Adjusting speed device of main motor		YASAKAWA OF JAPAN, F7
Electrical power		380V/50HZ
Net dimension of the machine	mm	6,100×2,210×1,790
Packing dimension of the machine	mm	1) 6,360×2,500×2,280 2)2000x860x2000
N. W./ G. W.	kg	1) 12000/ 15500 2)650/ 800
