X5057A China Ram Milling Machine at Lower Price

US$ 17,000 - 27,633 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Liaoning, China

Brand Name:

LFM

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian/Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Liaoning, China

Brand Name LFM

Model Number X5057A ram milling machine

Type Universal

CNC or Not Normal

Voltage 220V 380V 400V 415V 440V 480V

Power(W) 7.5kW

Dimension(L*W*H) 2986x2260x2180mm

Weight 5500kgs

Certification ISO9001:2008; GB/T19001:2008

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

X5057A China ram milling machine technical data

Main Features

Such ram milling machine has following features:

1. high strength HT-200 and high rigidity cast iron of bed;

2. guideways quenched and fine grinded;

3. x, y, z axis automatic feeding driven by servo motors;

4. ballscrew can be ordered specially;

5. CE Standard and CE Certificate;

6. DRO is available, too.

7. X5057A is equal to UWF15B

Main Technical Data

SPECIFICATIONS	UNIT	X5750A (UWF15B)
Table size	mm	500×2000
T-slots(NO.×width×pitch)	mm	5×18×80
Table travel (X×Y×Z)	mm	1500×700×500
Swivel angle of milling head	-	360°
Spindle taper	-	ISO50
Spindle speed range	r.p.m	(27) 30~2050
Table feed (X/Y/Z)	mm/min	10~1000/10~1000/5~500
Table rapid speed	mm/min	2200/2200/1100
Distance between spindle nose and table surface	mm	25~525
Distance from spindle center line to column	mm	55~755
Main motor power	kW	7.5
Feed motor	kW	AC servo motor X/Y:15NM; Z: 18NM
Max load	kg	1800
Overall size	mm	2986×2260×2180
weight	kg	5500
