Home Hydraulic Lift Home Use Hydraulic Cheap Home Lift for Disabled People

Name: Home Hydraulic Lift Home Use Hydraulic Cheap Home Lift for Disabled People
Brand: Jinchuan
SKU: 102725171

US$ 3,500 - 5,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Jinchuan

Model Number:

CJR-4

Jinan Jinchuan Hydraulic Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Jinchuan

Model Number CJR-4

Lift Mechanism Lift Chain

Lift Drive / Actuation Electric Motor

Power 2.2kw

Rated Loading Capacity 250KG

Min. Lifting Height 40mm

Max. Lifting Height 4000mm

Table Size 1500mm* 1100mm

Overall Dimensions 1500mm*1400mm*3000mm+1100mm

Weight 1200kg

Certification CE ISO

Warranty 12 Months

After-sales Service Provided Engineers available to service machinery overseas

ame	No.	Lift capacity (kg)	Materials
Hydraulic wheelchair lift	CJR-4		stainless steel or spraying plastics
Platform size	1500mm* 1100mm
Dimension	1500mm1400mm3000mm+1100mm
Max Platform Height	4000mm
Min Platform height	40mm
Configuration	Open through or front and side entrances
Speed	60mm/s
Load capacity	250KG
Self-weight	200~1000KG
Control voltage	24V/DC
Power Output	2.2kw
Power Input	220V/50HZ/25A (or customized for local power supply)
Drive System	Hydraulic
Control Mode	Inching Switch or Automatic
Drive Control	Self-resetting system
Overload	Protection Over current relay
Material of Platform	Stainless steel
Guard panel & drive cabinet (framework)	304 stainless steel
Control panel	Two Control panels, one is on the bottom, one on the top
Operation Panel	Polished Stainless steel(up down and Emergency drop valve)
Working Condition	Both indoors and outdoors
Working temperature	From -10°~60°C
Installation	Non-pit installation, directly fixed to concrete floor (the concrete floor below the platform shall not be lower than the ground)
Control Device	Calling box (installed on the wall nearby) and remote controller(Extra optional)
Emergency Stop	The lifting and lowering process can be stopped immediately by pressing the emergency button.
Safety device	Safety Interlock	Lock the platform when it is out of control
	Emergency lowering	The platform can be lowered by opening hydraulic valve manually or rolling screw rod.
	Auto-flap	Turn up after lifting
