Specifications
1 Size:width 0.3 m,to 7 m, length 100 m to 2000 m3 Usage:in river and lake bank or bottom
4 Weight: 90gsm to 600gsm
Overview
Nonwoven staple polyester geotextiles, Manufactured from Polyester fibres,they have a unique staple fibre blend and an inbuilt flexibility with the help of the needle punching technology. It Comprises variety of thicknesses, weight and forms and each has its own special function. For a long time, it is an idea choice to be used as they have unique properties that have economical benefits like less material be used, quick and easy installations.
Application
For its UV resistance, Chemical stability and compatibility of oil and water, there are at least 80 specific applications area for geotextiles that have been developed. Mainly on Separation, Drainage, Filtration, Reinforcement and Protection. In the really project, it could work well as below,
l Road Works
l Ground Stabilization
l Drainage and Filtration Systems
l Construction Works
l Waste Disposal Sites and Water Purifying Plants
Technical Date
International standard ASTM |
Unit |
A14 |
A19 |
A29 |
A44 |
mass per unit area |
g/sqm |
160 |
200 |
250 |
380 |
thickness |
mm |
1.2 |
1.6 |
2.2 |
2.8 |
Width deviation |
0.005 |
0.005 |
0.005 |
0.005 |
|
elongation at break |
30% |
35% |
40% |
50% |
|
Wide Strip Tensile Strength(MD/XMD) |
KN |
6.2/5 |
8.5/7 |
10.2/8.5 |
14.5/13.2 |
Grab Tensile Strength(MD/XMD) |
N |
535/450 |
750/670 |
1095/1020 |
1905/1720 |
CBR Burst Strength |
N |
650 |
970 |
1300 |
2000 |
Pore Size |
μm |
110 |
100 |
90 |
85 |
Coefficient of Permeability |
m/s |
34 |
34 |
34 |
34 |
Trapezoidal Tear Strength (MD/XMD) |
N |
240/220 |
305/295 |
430/385 |
700/660 |
Permittivity |
1/s |
2.4 |
2.2 |
1.8 |
1.2 |
Two layer,the outer layer is plastic film to protect wear and tear, and the inner layer is PE film to seal for water.
Strong packed, and ease for long distance transport and shipment.
Continuous Improvements and Innovations
High quality and Low cost
Enhance Customer Satisfactions
