1.Procuce details
Name |
Cylindrical Roller Bearing NU228M NJ228EM NJ230EM NU232EM NJ232EM |
Ring material |
Chrome Steel GCr15 |
Brand |
LYDC |
Precision |
P0,P6,P5, |
Clearance: |
C2 ,C3, C4 |
Port |
Wuhan, Shanghai ,Ningbo or your requied |
Samples |
Available |
Service |
OEM |
Payment terms |
L/C, T/T, cash |
Application |
Suitable For Large And Medium-sized Motors,Rolling Stock,Machine Tool,Spindles,Interanal Combustion Engines,Generators,Gas Turbine,Gearbox,Rolling Mill,Vibrating Screen And Hoisting And Conveying Machinery. |
Series |
1. Single row tapered roller bearings |
2. Double row tepered roller bearings | |
3. Four row tapered roller bearings | |
4. Paired single row tpered roller bearings | |
Features |
1.High quality and good service |
2.Less friction and low noise | |
3.Competitve price | |
4.Durable | |
5.Professional manufacturer of ball bearing and roller bearing |
2)Minimum lubrication
3)Wear resistant
4)Dimensions relatively small
5)Easy replacement
a. single row cylindrical roller bearings, cage, mainly of the NU,NJ,NUP, and N designs.
b. double row cylindrical roller bearings, caged, mainly of the NNU and NN designs.
c. multi-row cylindrical roller bearings, caged.
d. single row full complement cylindrical roller bearings, mainly of the NCF and NJG designs.
e. double row full complement cylindrical roller bearings, mainly of the NNF design.
f. multi-row full complement cylindrical roller bearings, with four rollers.
N type of bearing housing washer no guard, both sides of the inner ring has guard.
Can allow shaft relative bearing between the axial two direction of displacement.
NU type of bearing's outer two guard, inner ring no guard. Can also allow shaft relative
bearing between the axial two direction of displacement. Therefore, this kind of structure
is suitable for use as a floating end bearing.
NJ type of bearing housing washer two guard, the inner ring of the unilateral have guard.
May have a certain amount of unilateral axial load.
NF type of bearing unilateral have outer rim, the inner ring of the two guard. Also can bear
a certain amount of unilateral axial load. Therefore, this kind of structure is suitable for single
direction as the axial location bearing with.
NUP type of bearing outer is two guard, inner ring side band (fixed) single guard, and the
other side is separable flat ring. May have a certain amount of two-way axial load
Application
Cylindrical roller bearings widely used in Large and medium-sized motor, locomotives,
spindle, internal combustion engine, generator, gas turbines, reducer, rolling mill,
vibrating screen and lifting transportation machinery, etc.
Packaging
(1)plastic bag + kraft paper + carton box + plywood pallet
(2). As the customers' requirement.
Delivery Details:10-20 days
| Ball Bearing | Deep Groove Ball Bearing |
60 **,618 ** (1008), 619**(1009),62 **, 63 **, 64 **, 160 **(70001 ) |
| Thrust Ball Bearing | 511 ** (81) ,512 **(82) ,513 (83) ,514 ** (84) series and Angular Contact Thrust all Bearings like: 5617 ** (1687) ,5691 ** (91681), 5692 ** (91682) series |
|
| Angular Contact Ball bearing | SN718 **(11068 ) ,70 ** 72 **,73 **, and B (66), C (36), AC (46) series ; otherwise include QJ and QJF series |
|
| Roller Bearing | Spherical Roller bearing | 239**, 230**,240**, 231**, 241**, 222**, 232**, 223**, 233**, 213**, 238**, 248**, 249**and special series include 26** i.e 2638 (3738), 2644 (3844) and so on |
| Taper Roller Bearing | 329**(20079),210**(71), 320**(20071),302**(72), 322**(75), 303**(73), 313**(273),323**(76), 3519**(10979), 3529**(20979),3510**(971), 3520**(20971),3511**(10977), 3521**(20977), 3522**(975), 319**(10076),3819**(10779),3829**(20779), 3810**(777,771), 3820**(20771), 3811**(10777,777) for example: 77752, 77788, 77779 and also include Inch series bearings suchas 938/932 single and double row i.e M255410CD etc. |
|
| Thrust Roller Bearing | 292**(90392), 293**(90393),294**(90394),994**(90194), and 9069 series. |
|
| Cylindrical Roller Bearing |
NU10**, NU2**,NU22**, NU3**,NU23**, NU4**, N, NJ ,NUP series as well as NB, NN, NNU series of big bearings, and we also have Split Bearings 412740, 422740 used in cement industry.And FC, FCD series used inSteel Industry. |
Who we are?
Wuhan East Technology Co., Ltd. was established in Hubei in 2007, is specialized in
producing and exporting all kinds of bearings. Our bearings’ quality is always under
strict control. Our factory has the most advanced production facilities and we can also
provide custom-made for various non-standard bearings as per your requirements.We
will try our best to serve you and hope to become one of your friends and business partners.
Why choose us?
1.7 years bearing products manufacturing experience.
2.High quality and reasonable price.
3.Various sizes of bearing are available.
4.We can offer free sample.
5.Fast delivery.
6.Quick respond to your inquiry all the time.
7.We can offer OEM Service
8.We are manufacturer&export company.
1.Could you supply sample for free?
Yes, we can supply sample for free, but need our customer afford freight.
2.Could you tell me the delivery time of your goods?
3-7 days stock goods and other goods according to the quantity about 3-21 days.
3.Can we customize the bearings?
Yes, sure. We can customize the bearings as your requirements.
4.How does your factory do regarding quality control?
Quality first is our principle.We always attach great importance to quality control from the
every beginning to the end of the production. Every product will be fully
assembled and carefully tested
