Specifications
1.Low start wind speed .2.No vibration & low noise.
3.All of our products confirm to CE.
4.2-year warranty for generator.
2014 newest 30KW wind energy generator (Curved Blade)
1.Product Description:
Form-1: Technical parameters:
Power |
30kw |
Type of generator |
Permanent-magnet 360v A.C. (Voltage optional) |
Rotor diameter: |
7.6m |
Blade Material: |
FRP (Fiber glass reinforced*3) |
Rated rotor speed |
60r/min |
Rated wind speed |
13m/s |
Rated Power |
30kw |
Max Power |
32kw |
Start up wind speed |
3(m/s) |
Work speed |
3-25(m/s) |
Security wind speed |
40(m/s) |
Height of guy cable tower |
15m |
Number of blade |
7 |
Output controller system |
Controller , Inverter |
Form-2: Blades:
FRP, (Fiber Reinforced Polymer) acronym, the existing CFRP, GFRP, AFRP, BFRP so on.
Chinese in FRP refers GFRP. FRP composite material is a fiber material of the base material
according to a certain mixing ratio, after a special extrusion die, drawing the formation of
high-performance materials.Since the resin used in different varieties, so there are glass fiber
reinforced polyester, glass fiber reinforced epoxy , phenolic FRP said. Light and hard,
non-conductive, high mechanical strength, recycling less resistant to corrosion.
Form-3: The inverter:
1.digital design, simple structure, powerful, stable and reliable
2.using annular isolation no-load loss of transformer, inverter with high efficiency
3.pure sine wave, automatic voltage regulator, output and frequency, waveform distortion rate ≤ 5%
4.strong overload capacity, 120% overload can work normally for 1 minutes; 150% overload can
work normally for 10 seconds
5.high reliability; high stability; high shock resistance; low noise, noise≤ 40dB
6.input / output circuit complete isolation design, improve product stability
7.has over-voltage, under-voltage, overload, overheating, short circuit, lightning protection function
and alarm function
Form-3: 30kw wind turbine curve:
2.Product advantages:
1.Unique waterproof, moisture-proof, anti-dust, anti-salt spray design.
2.High-strength, corrosion-resistant special glass fiber reinforced plastic material.
3.On-grid or Off-grid wind power system optional.
4. 2-year warranty for generator and 18-20 years service life.
3.packaging and shipping:
In plywood boxes.
1.Small size, light weight, easy to transport and install.
2.Intuitive online installation instructions.
3.Global coverage of the installation and maintenance .
4.Improved after sale access and service system.
4.Quality assurance:
1.One year warranty for whole system.
2.Preferred anti-corrosion, rust-proof special materials and high-strength parts.
3.ISO9001 management system strictly control.
4.Adapt to the working environment temperature -50 °C ~120 °C.
5.Company Profiles:
Qingdao Richuan precision Machinery Co,Ltd. is a manufacture enterprise which
develops, manufactures and sells small and medium complete set of wind turbine.
Normally we produce the vertical axis and the horizontal axis wind-driven generator.
Our company has design department and system configuration team, thus we can
provide power supply system solutions depending on various customers' requirements.
Moreover, we have engineering department, our engineers can provide product's
installation guidance and training to our customers.
Note
1. Tower type and tower height can be changed as per your request.
2. Working voltage can be made for your country grid.
3. For the details,please feel free to contact us.
