Help CenterProfessional Power Amplifier CA9
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
CHANGCHENG LT
Model Number:
CA9
Type:
Professional Amplifier
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
CHANGCHENG LT
Model Number
CA9
Type
Professional Amplifier
Channels
2 (2.0)
Place of Origin
Guangdong, China
Specifications
CA series have 2U-3U higher selection, and 150W-1100W power area.CA series have 2U-3U higher selection, and 150W-1100W power area, CA series had some pursuits for faster of reaction speed higher of damping factor, and greater function, higher level of protect function,production technology of SMD excellent component. Amplifier of CA series also can endure 2Ω stereo load, bridge 4Ω load, suit for drive line array speaker system.
| Model | CA2 | CA4 | CA6 | CA9 | CA12 | CA18 | CA20 |
| 8ΩStereo Power | 150W | 250W | 400W | 520W | 800W | 1100W | 1300W |
| 4ΩStereo Power | 225W | 375W | 600W | 780W | 1200W | 1800W | 1950W |
| 2ΩStereo Power | 270W | 500W | 800W | 1040W | 1600W | 2200W | 2600W |
| 8ΩBTL | 450W | 750W | 1200W | 1560W | 2400W | 3600W | 3900W |
| 4ΩBTL | 540W | 1000W | 1600W | 2080W | 3200W | 4400W | 5200W |
| Frequency Response | 20--20K+0/-0.3dB | ||||||
| THD+N | <0.03%@8Ω1Hz | ||||||
| S/N Ratio | >90dB | >90dB | >95dB | >95dB | >93dB | >93dB | >93dB |
| Slew Ratio | 20V/uS | 20V/uS | 30V/uS | 30V/uS | 40V/uS | 44V/uS | 44V/uS |
| Damping Factor | >400 | >400 | >400 | >400 | >300 | >300 | >300 |
| Crosstalk | >70dB@8Ω1KHz | ||||||
| Input Lmpedance | 20KΩ(Balance)/10KΩ(Unbalance) | ||||||
| Input Sensitivity | 0.775V/1.0/1.4V | ||||||
| Protect | Overheat short circuits,DC,limit and--softstart,Output relay-Zero | ||||||
| Current Switch,Intellctual Clip limiter. | |||||||
| Heigh | 2U | 2U | 2U | 2U | 3U | 3U | 3U |
| Cross Weight | 21KG | 23KG | 26KG | 27.5KG | 42.5KG | 43KG | 47KG |
| Dimensions | 570*570*150mm | 650*585*200mm | |||||
