Help CenterSerrated Bar Grating
Negotiable
MOQ: 25 Tons (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Standard:
ASTM
Grade:
carbon steel
Dimensions:
32*5mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Standard
ASTM
Grade
carbon steel
Dimensions
32*5mm
Place of Origin
Hebei, China
Brand Name
BLD
Model Number
32*5mm
Type
Carbon Structural Steel
Application
power station
Shape
Angle
Specifications
Steel GratingMaterial: 1)Aluminum 2)Carbon steel 3)Stainess steel
Steel Grating
Material: 1)Aluminum 2)Carbon steel 3)Stainess steel
Type: 1)Plain surface 2)Serrated surface 3)"I"bar type 4)Press lock
Finish: 1)Uncoated 2)Galvanized 3)Powder coated
Usage: Power plants, Chemical plants, Oil refinery, Steel plants, Machineries plants, Paper-making factories, Cement plants, Civil engineering, Wastewater treatment, Pharmacy industry, etc.
| GALVANISED TRANSVERSE TRENCH GRATING |
| A | B | ||||
| Product | Grate | Grate | Load Bars | Edge Bar | Cross Bar |
| Code | Width mm | Depth mm | Size | Size | Size |
| GG150 | 150 | 20 | 20 x 5 @ 40mm c/c | 20 x 5 | 6mm @ 100 c/c |
| GG230 | 230 | 25 | 25 x 5 @ 40mm c/c | 25 x 5 | 6mm @ 100 c/c |
| GG300 | 300 | 25 | 25 x 5 @ 40mm c/c | 25 x 5 | 6mm @ 100 c/c |
| GG210HD | 210 | 32 | 32 x 5 @ 30mm c/c | 32 x 5 | 6mm @ 100 c/c |
| GG310HD | 310 | 40 | 40 x 5 @ 30mm c/c | 40 x 5 | 6mm @ 100 c/c |
| GG380HD | 380 | 40 | 40 x 5 @ 30mm c/c | 40 x 5 | 6mm @ 100 c/c |
| GALVANISED STORMWATER PIT GRATING |
| Product | Grate | Grate | Load Bars | Edge Bar | Cross Bar |
| Code | Width mm | Length mm | Size | Size | Size |
| SPG4L | 540 | 540 | 25 x 5 @ 40mm c/c | 50 x 5 | 6mm @ 100 c/c |
| SPG4H | 540 | 540 | 50 x 5 @ 40mm c/c | 50 x 5 | 6mm @ 100 c/c |
| SPG6L | 690 | 690 | 25 x 5 @ 40mm c/c | 50 x 5 | 6mm @ 100 c/c |
| SPG6H | 690 | 690 | 50 x 5 @ 40mm c/c | 50 x 5 | 6mm @ 100 c/c |
| SPG96L | 690 | 990 | 25 x 5 @ 40mm c/c | 50 x 5 | 6mm @ 100 c/c |
| SPG96H | 690 | 990 | 50 x 5 @ 40mm c/c | 50 x 5 | 6mm @ 100 c/c |
| SPG9L | 690 | 990 | 25 x 5 @ 40mm c/c | 50 x 5 | 6mm @ 100 c/c |
| SPG9H | 990 | 990 | 50 x 5 @ 40mm c/c | 50 x 5 | 6mm @ 100 c/c |
| SPG12L | 1290 | 645 | 25 x 5 @ 30mm c/c | 50 x 5 | 6mm @ 100 c/c |
| SPG12H | 1290 | 645 | 50 x 5 @ 30mm c/c | 50 x 5 | 6mm @ 100 c/c |
